The products that we source are either traded back-to-back or used for our own blending and processing and further sales to end consumers. Our trade partners include major players in the field as well as smaller firms and we deal with governmental and private buyers as well as public companies. Our focus is on bulk liquid products, in particular clean oil products, chemicals, aromatics and liquefied petroleum gas (LPG). in addition, VOGAS is an active player in polymer, bitumen, catalyst and additive markets.
| Process | Usage |
|---|---|
| Propylene -Ammoxidation | Titanium Tetrachloride is a raw material for synthesis |
| Process | Usage |
|---|---|
| Propylene -Ammoxidation |
| Process | Usage |
|---|---|
| Unipol |
| Process | Usage |
|---|---|
| Mitsui CX HDPE |
| Process | Usage |
|---|---|
| Mitsui CX HDPE |
| Process | Usage |
|---|---|
| Spheripol | It can be used to make homo, random,high impact copolymer products with MFR from 0.1-60g/10min. |
| Spherizone | It can be used to make homo, random,high impact copolymer products with MFR from 0.1-60g/10min. |
| Process | Usage |
|---|---|
| Spheripol | It can be used to make homo, random,high impact copolymer products with MFR from 0.1-60g/10min. |
| Process | Usage |
|---|---|
| Spheripol | It can be used to make homo,random products with MFR from 0.1-60g/10min. |
| Process | Usage |
|---|---|
| Hypol | It can be used to make homo,random, heco products with MFR from 0.1-60g/10min. |
| Spheripol | It can be used to make homo,random, heco products with MFR from 0.1-60g/10min. |
| Gas Phase | It can be used to make homo,random, heco products with MFR from 0.1-60g/10min. |
| Process | Usage |
|---|---|
| Hypol | It can be used to make homo,random, with MFR from 0.1-40g/10min. |
| Slurry | It can be used to make homo,random, with MFR from 0.1-40g/10min. |
| Process | Usage |
|---|---|
| Hypol | It can be used to make homo,random,heco products with MFR from 0.1-40g/10min. |
| Spheripol | It can be used to make homo,random,heco products with MFR from 0.1-40g/10min. |
| Property | Unit | Test | Value |
|---|---|---|---|
| Congealing Point | ASTM D-938 | 60-63 C | |
| Oil content | ASTM D-721 | <1% | |
| Kinematic Viscosity@100 C | ASTM D-445 | 4-6 cst | |
| Drop Melting Point | ASTM D-127 | 60-66 C | |
| Flash Point | ASTM D-92 | Min 190 C | |
| Color (Lovibond) | <1.5 Y | ||
| Odor | Odorless |
| Property | Unit | Test | Value |
|---|---|---|---|
| Types | Unbleached Paraffin Wax Paraffin Wax | ||
| Color, Max | ASTM D-1500 | 1.5 White | |
| Kinematic Viscosity @ 100 °C | cSt | ASTM D-445 | 6-7.5 6.5-7 |
| Oil Content, Max. | %wt | ASTM D-721 | 1.5% 1.5% |
| Melting Point | °C | ASTM D-87 | 60-68 60-66 |
| Property | Unit | Test | Value |
|---|---|---|---|
| Mooney Viscosity (ML 1+4 @100 oC) | MU | ASTM D1646 | 41-49 |
| Cis Content | wt% | Internal Method | MIN 96 |
| Volatile Material | wt% | ASTM D1646 | MAX 0.75 |
| Ash Content | wt% | ASTM D1646 | MAX 0.3 |
| Compound Mooney Viscosity | MU | ASTM D - 1646 | MAX 77 |
| Tensile Strenght (35min) | Kgf/m³ | ASTM D 412 | MIN150 |
| Elongation at Break (35min) | % | ASTM D 412 | MIN 440 |
| 300% Modulus at 145 oC) | |||
| 25 Min | Kgf/m³ | ASTM D 412 | 68-108 |
| 35 Min | Kgf/m³ | ASTM D 412 | 74-114 |
| 50 Min | Kgf/m³ | ASTM D 412 | 74-114 |
| Property | Unit | Test | Value |
|---|---|---|---|
| Mooney viscosity (ML 1+4 @ 100 oC) | MU | ASTM D1646 | 46-58 |
| Mooney viscosity (ML 1+4 @ 100 oC)-compound² | MU | ASTM D1646 | <84 |
| Volatile matters | % wt. | ASTM D5668 | < 0.75 |
| Total ash | % wt. | ASTM D5667 | < 1.5 |
| Organic acids | % wt. | ASTM D5774 | 4.5 -7 |
| Soaps | % wt. | ASTM D5774 | < 0.5 |
| Bounded styrene | % wt. | ASTM D5775 | 22.5-24.5 |
| Tensile strength(35 min cured)² | kg/cm² | ASTM D 412 | >250 |
| Ultimate elongation(35 min cured)² | % | ASTM D 412 | >350 |
| 300 % Modulus(35 min cured)² | kg/cm² | ASTM D 412 | 167-207 |
| Property | Unit | Test | Value |
|---|---|---|---|
| BEAD SIZE | MM | SUNPOR 7.2.5 (MIN 90% BY WT) | (0.3-0.5)(>90%wt) |
| K-VALUE | SUNPOR 7.2.4 | 55 | |
| PENTANE CONTENT | WT% | SUNPOR 7.2.2 | >5.2% |
| BULK DENSITY | KG/M3 | SUNPOR 7.2.3 | 22-30 |
| RESIDUAL MONOMER | PPM | SUNPOR 7.2.1 | 500 |
| Property | Unit | Test | Value |
|---|---|---|---|
| BEAD SIZE | MM | SUNPOR 7.2.5 (MIN 90% BY WT) | (0.5-0.7)(>90%wt) |
| K-VALUE | SUNPOR 7.2.4 | 55 | |
| PENTANE CONTENT | WT% | SUNPOR 7.2.2 | >5% |
| BULK DENSITY | KG/M3 | SUNPOR 7.2.3 | 20-30 |
| RESIDUAL MONOMER | PPM | SUNPOR 7.2.1 | 500 |
| Property | Unit | Test | Value |
|---|---|---|---|
| BEAD SIZE | MM | SUNPOR 7.2.5 (MIN 90% BY WT) | (1.8-2.5)(>90%wt) |
| K-VALUE | SUNPOR 7.2.4 | 55 | |
| PENTANE CONTENT | WT% | SUNPOR 7.2.2 | 5.20% |
| BULK DENSITY | KG/M3 | SUNPOR 7.2.3 | 13-15 |
| RESIDUAL MONOMER | PPM | SUNPOR 7.2.1 | 500 |
| Property | Unit | Test | Value |
|---|---|---|---|
| BEAD SIZE | MM | SUNPOR 7.2.5 (MIN 90% BY WT) | (1-1.8)(>90%wt) |
| K-VALUE | SUNPOR 7.2.4 | 55 | |
| PENTANE CONTENT | WT% | SUNPOR 7.2.2 | 5.20% |
| BULK DENSITY | KG/M3 | SUNPOR 7.2.3 | 14-30 |
| RESIDUAL MONOMER | PPM | SUNPOR 7.2.1 | 500 |
| Property | Unit | Test | Value |
|---|---|---|---|
| BEAD SIZE | MM | SUNPOR 7.2.5 (MIN 90% BY WT) | (0.7-1)(>90%wt) |
| K-VALUE | SUNPOR 7.2.4 | 55 | |
| PENTANE CONTENT | WT% | SUNPOR 7.2.2 | 5.20% |
| BULK DENSITY | KG/M3 | SUNPOR 7.2.3 | 18-30 |
| RESIDUAL MONOMER | PPM | SUNPOR 7.2.1 | 500 |
| Property | Unit | Test | Value |
|---|---|---|---|
| BEAD SIZE | MM | SUNPOR 7.2.5 (MIN 90% BY WT) | (0.3-0.5)(>90%wt) |
| K-VALUE | SUNPOR 7.2.4 | 55 | |
| PENTANE CONTENT | WT% | SUNPOR 7.2.2 | 5.20% |
| BULK DENSITY | KG/M3 | SUNPOR 7.2.3 | 22-30 |
| RESIDUAL MONOMER | PPM | SUNPOR 7.2.1 | 500 |
| Property | Unit | Test | Value |
|---|---|---|---|
| MELT FLOW INDEX(200°C-5KG) | g/10min | D1238 | 14 |
| STYRENE RESIDUAL MONOMER | PPM | CLG LABPSG004 (ATOFINA TEST METHOD) | <500 |
| VICAT SOFTENING POINT ( 120 °C/hr 1kg) | °C | D1525 | 90 |
| TENSILE STRENGTH | MPa | D638 | 40 |
| CHARPY IMPACT STRENGTH | Kj/m2 | D256 | 8 |
| FLEXURAL MODULUS | MPa | D790 | 2900 |
| Property | Unit | Test | Value |
|---|---|---|---|
| MELT FLOW INDEX(200°C-5KG) | g/10min | ASTM D 1238 | 10 |
| STYRENE RESIDUAL MONOMER | PPM | CLG LABPSG004 (ATOFINA TEST METHOD) | <500 |
| VICAT SOFTENING POINT ( 50 °C/hr1kg) | °C | ASTM D 1525 | 95 |
| TENSILE STRENGTH AT BREAK | MPA | ASTM D 638 | 42 |
| ELONGATION AT BREAK | % | ASTM D 638 | 2.5 |
| TENSILE MODULUS | MPA | ASTM D 638 | 2900 |
| WATER ABSORPTION | % | ASTM D 570 | <0.1 |
| MOULDING SHRINKAGE | % | ASTM D 955 | 0.4 – 0.8 |
| DENSITY | g/cm3 | ASTM D 792 | 1.04 |
| Property | Unit | Test | Value |
|---|---|---|---|
| MELT FLOW INDEX(200°C-5KG) | g/10min | D1238 | 7 |
| STYRENE RESIDUAL MONOMER | PPM | CLG LABPSG004 | <500 |
| VICAT SOFTENING POINT ( 120 °C/hr 1kg) | °C | (ATOFINA TEST METHOD) | 98 |
| TENSILE STRENGTH | MPa | D1525 | 52 |
| CHARPY IMPACT STRENGTH | Kj/m2 | D638 | 8 |
| FLEXURAL MODULUS | MPa | D256 | 3100 |
| Property | Unit | Test | Value |
|---|---|---|---|
| MELT FLOW INDEX(200°C-5KG) | g/10min | D1238 | 3.8 |
| STYRENE RESIDUAL MONOMER | PPM | CLG LABPSG004 (ATOFINA TEST METHOD) | <500 |
| VICAT SOFTENING POINT ( 120 °C/hr 1kg) | °C | D1525 | 99 |
| TENSILE STRENGTH | MPA | D638 | 50 |
| CHARPY IMPACT STRENGTH | Kj/m2 | D256 | 10 |
| FLEXURAL MODULUS | MPa | D790 | 3100 |
| Property | Unit | Test | Value |
|---|---|---|---|
| MELT FLOW INDEX(200°C-5KG) | g/10min | D1238 | 3.1 |
| STYRENE RESIDUAL MONOMER | PPM | CLG LABPSG004 (ATOFINA TEST METHOD) | <500 |
| VICAT SOFTENING POINT ( 120 °C/hr 1kg) | °C | D1525 | 101 |
| TENSILE STRENGTH | MPa | D638 | 55 |
| CHARPY IMPACT STRENGTH | Kj/m2 | D256 | 10 |
| FLEXURAL MODULUS | MPa | D790 | 3100 |
| Property | Unit | Test | Value |
|---|---|---|---|
| MELT FLOW INDEX(200°C-5KG) | g/10min | D1238 | 2.4 |
| STYRENE RESIDUAL MONOMER | PPM | CLG LABPSG004 (ATOFINA TEST METHOD) | <500 |
| VICAT SOFTENING POINT ( 120 °C/hr 1kg) | °C | D1525 | 102 |
| TENSILE STRENGTH | MPa | D638 | 55 |
| CHARPY IMPACT STRENGTH | Kj/m2 | D256 | 11 |
| FLEXURAL MODULUS | MPa | D790 | 3200 |
| Property | Unit | Test | Value |
|---|---|---|---|
| Melt Flow Rate ( 230 °C, 2.16 kg) | g/10 min | ASTM D1238 | 50 |
| Density | Kg/m³ | ASTM D1505 | 0.9 |
| Flexural Modulus | MPa | ASTM D790 | 1500 |
| Tensile Strength at Yield | MPa | ASTM D638 | 28 |
| Tensile Elongation at Yield | % | ASTM D638 | 5 |
| Izod Impact Strength (notched) at 23 °C | J/m | ASTM D256 | 60 |
| Izod Impact Strength (notched) at -20 °C | R Scale | ASTM D256 | 30 |
| Rockwell Hardness | R Scale | ASTM D785 | 100 |
| Vicat softening point (10N) | °C | ASTM D1525 | 151 |
| H.D.T. (0.46 Mpa) | °C | ASTM D648 | 95 |
| Accelerated oven ageing in air at 150 °C | hours | ASTM D3012 | 360 |
| Property | Unit | Test | Value |
|---|---|---|---|
| Melt Flow Rate ( 230 °C, 2.16 kg) | g/10 min | ISO 1133 | 1.3 |
| Density | Kg/m³ | ISO 1183 | 0.9 |
| Flexural Modulus | MPa | ISO 527-1, -2 | 1450 |
| Tensile Strength at Yield | MPa | ISO 527-1, -2 | 27 |
| Tensile Elongation at Break | % | ISO 527-1, -2 | > 50 |
| Tensile Elongation at Yield | % | ISO 527-1, -2 | 8 |
| Charpy impact strength (Notch A) | ISO 179 | ||
| 23°C | KJ/m² | 40 | |
| 0°C | KJ/m² | 9 | |
| Gloss (60°) | ----- | DIN 67530 | 65 |
| Property | Unit | Test | Value |
|---|---|---|---|
| Melt Flow Rate ( 230 °C, 2.16 kg) | g/10 min | ASTM D1238 | 6 |
| Density | Kg/m³ | ASTM D1505 | 0.9 |
| Flexural Modulus | MPa | ASTM D790 | 1400 |
| Tensile Strength at Yield | MPa | ASTM D638 | 26 |
| Tensile Elongation at Yield | % | ASTM D638 | 9 |
| Izod Impact Strength (notched) at 23 °C | J/m | ASTM D256 | 170 |
| Izod Impact Strength (notched) at -20 °C | R Scale | ASTM D256 | 70 |
| Shore Hardness (Shore D) | ----- | ISO 868 | 68 |
| Vicat softening point (10N) | °C | ASTM D1525 | 152 |
| H.D.T. (0.46 Mpa) | °C | ASTM D648 | 95 |
| Accelerated oven ageing in air at 150 °C | hours | ASTM D3012 | 360 |
| Property | Unit | Test | Value |
|---|---|---|---|
| Melt Flow Rate ( 230 °C, 2.16 kg) | g/10 min | ASTM D1238 | 21 |
| Density | Kg/m³ | ASTM D1505 | 0.9 |
| Flexural Modulus | MPa | ASTM D790 | 1500 |
| Tensile Strength at Yield | MPa | ASTM D638 | 27 |
| Tensile Elongation at Yield | % | ASTM D638 | 7 |
| Izod Impact Strength (notched) at 23 °C | J/m | ASTM D256 | 85 |
| Izod Impact Strength (notched) at -20 °C | R Scale | ASTM D256 | 50 |
| Rockwell Hardness | R Scale | ASTM D785 | 98 |
| Vicat softening point (10N) | °C | ASTM D1525 | 149 |
| H.D.T. (0.46 Mpa) | °C | ASTM D648 | 110 |
| Accelerated oven ageing in air at 150 °C | hours | ASTM D3012 | 360 |
| Property | Unit | Test | Value |
|---|---|---|---|
| Melt Flow Rate ( 230 °C, 2.16 kg) | g/10 min | ASTM D1238 | 38 |
| Density | Kg/m³ | ASTM D1505 | 0.9 |
| Tensile Modulus | MPa | ASTM D790 | 1150 |
| Tensile Strength at Yield | MPa | ASTM D638 | 28 |
| Tensile Elongation at Yield | % | ASTM D638 | 11 |
| Izod Impact Strength (notched) at 23°C | J/m | ASTM D785 | 55 |
| Rockwell Hardness | R-Scale | ASTM D785 | 94 |
| Accelerated oven ageing in air at 150° C | hourse | ASTM D3012 | 360 |
| Haze (1mm) | % | ASTM D1003 | 12 |
| Vicat softening point (10N) | °C | ASTM D1525 | 128 |
| H.D.T. B (0.45 MPa) | °C | ASTM D648 | 70 |
| Property | Unit | Test | Value |
|---|---|---|---|
| Melt Flow Rate ( 230 °C, 2.16 kg) | g/10 min | ASTM D1238/L | 0.25 |
| Density | Kg/m³ | ASTM D792 | 0.91 |
| Tensile Modulus of Elasticity (1mm/min) | MPa | ASTM D638 | 850 |
| Tensile Strength at Yield (50 mm/min) | MPa | ASTM D638 | 25 |
| Elongation at Yield(50 mm/min) | % | ASTM D638 | 10 |
| Notched Charpy Impact at 23? | KJ/m² | ISO 179/ 1eA | 20 |
| Notched Charpy Impact at -30? | KJ/m² | ISO 179/ 1eA | 2.5 |
| Vicat Softening Point, 10N | °C | ASTM D1525 | 132 |
| Ball Indentation Hardness | MPa | ISO 2039-1 | 45 |
| HDT ( 0.46 N/mm2 ) | °C | ASTM D648 | 75 |
| Melting Point , DSC | °C | ASTM D3417 | 145 |
| Property | Unit | Test | Value |
|---|---|---|---|
| Melt Flow Rate ( 230 °C, 2.16 kg) | g/10 min | ISO 1133 | 0.6 |
| Density | Kg/m³ | ISO 1183 | 0.9 |
| Flexural Modulus | MPa | ISO 527-1, -2 | 1000 |
| Tensile Strength at Yield (50 mm/min) | MPa | ISO 527-1, -2 | 25 |
| Tensile Elongation at Yield (50 mm/min) | % | ISO 527-1, -2 | 10 |
| Flexural Modulus (2 mm/min) | Mpa | ISO 178 | 1100 |
| Charpy impact strength (notched) at 23?C | Kj/m2 | ISO 179 | 20 |
| Melting temperature | ?C | ISO 3146 | 148 |
| Property | Unit | Test | Value |
|---|---|---|---|
| Melt flow rate (190 °C, 5 kg) | g/10min | D 1238 L | 0.4-0.6 |
| Hardness Rockwell | |||
| Linear coefficient of Expansion | mm/(mx°C) | D 696 | 0.11 |
| Thermal conductivity (23°C) | 0.89 | ||
| Specific gravity | D 792 | ||
| Mechanical properties | |||
| Flexural modulus | MPa | D 790 | 9.5 |
| Tensile strength at yield | MPa | D 638 | 28 |
| Elongation at break | % | D 638 | >430 |
| Notched Izod impact strenght | J/m | D 256 | NB |
| Unnotched Izod imp.strenght | J/m | D 256 | NB |
| Vicat softening point (9.8N) | °C | D 1525 | 135 |
| H.D.T. (0.45 Mpa) | °C | D 648 | 80 |
| Accelerated öven ageing at 135°C | hours | D 3012 | >9,000 |
| Property | Unit | Test | Value |
|---|---|---|---|
| Melt Flow Rate ( 230 °C, 2.16 kg) | g/10 min | ASTM D1238 | 25 |
| Density | Kg/m³ | ASTM D1505 | 0.9 |
| Flexural Modulus | MPa | ASTM D790 | 1050 |
| Tensile Strength at Yield | MPa | ASTM D638 | 28 |
| Tensile Elongation at Yield | % | ASTM D638 | 12 |
| Izod Impact Strength (notched) at 23 °C | J/m | ASTM D256 | 65 |
| Rockwell Hardness | R Scale | ASTM D785 | 94 |
| Vicat softening point (10N) | °C | ASTM D1525 | 127 |
| H.D.T. (0.46 Mpa) | °C | ASTM D648 | 83 |
| Accelerated oven ageing in air at 150 °C | hours | ASTM D3012 | 360 |
| Haze (1mm) | % | ASTM D1003 | 22 |
| Gloss (60?) | --- | ASTM D2457 | 73 |
| Property | Unit | Test | Value |
|---|---|---|---|
| Melt Flow Rate ( 230 °C, 2.16 kg) | g/10 min | ASTM D1238 | 11 |
| Density | Kg/m³ | ASTM D1505 | 0.9 |
| Flexural Modulus | MPa | ASTM D790 | 1050 |
| Tensile Strength at Yield | MPa | ASTM D638 | 28 |
| Tensile Elongation at Yield | % | ASTM D638 | 12 |
| Izod Impact Strength (notched) at 23 °C | J/m | ASTM D256 | 85 |
| Rockwell Hardness | R Scale | ASTM D785 | 94 |
| Vicat softening point (10N) | °C | ASTM D1525 | 128 |
| H.D.T. (0.46 Mpa) | °C | ASTM D648 | 83 |
| Accelerated oven ageing in air at 150 °C | hours | ASTM D3012 | 360 |
| Haze (1mm) | % | ASTM D1003 | 9 |
| Gloss (60?) | --- | ASTM D2457 | 85 |
| Property | Unit | Test | Value |
|---|---|---|---|
| Melt Flow Rate ( 230 °C, 2.16 kg) | g/10 min | ASTM D1238 | 25 |
| Density | Kg/m³ | ASTM D1505 | 0.9 |
| Flexural Modulus | MPa | ASTM D790 | 1500 |
| Tensile Strength at Yield | MPa | ASTM D638 | 32 |
| Tensile Elongation at Yield | % | ASTM D638 | 13 |
| Izod Impact Strength (notched) at 23 °C | J/m | ASTM D256 | 30 |
| Rockwell Hardness | R Scale | ASTM D785 | 100 |
| Vicat softening point (10N) | °C | ASTM D1525 | 152 |
| H.D.T. (0.46 Mpa) | °C | ASTM D648 | 94 |
| Accelerated oven ageing in air at 150 °C | hours | ASTM D3012 | 150 |
| Property | Unit | Test | Value |
|---|---|---|---|
| Melt Flow Rate ( 230 °C, 2.16 kg) | g/10 min | ASTM D1238 | 3.2 |
| Density | Kg/m³ | ASTM D1505 | 0.9 |
| Flexural Modulus | MPa | ASTM D790 | 1550 |
| Tensile Strength at Yield | MPa | ASTM D638 | 35 |
| Tensile Elongation at Yield | % | ASTM D638 | 12 |
| Izod Impact Strength (notched) at 23 °C | J/m | ASTM D256 | 55 |
| Rockwell Hardness | R Scale | ASTM D785 | 102 |
| Vicat softening point (10N) | °C | ASTM D1525 | 156 |
| H.D.T. (0.46 Mpa) | °C | ASTM D648 | 94 |
| Accelerated oven ageing in air at 150 °C | hours | ASTM D3012 | 360 |
| Property | Unit | Test | Value |
|---|---|---|---|
| Intrinsic Viscosity | dl/g | UBBELHODE | 0.64 ± 0.01 |
| DEG content | %wt | GC | 1.4 ± 0.4 |
| Color (CIE Lab) | L-value ;b-value | SPECTROSCOPY | ? 75;? 4.5 |
| Carboxyl End Group | mmol/kg | SPECTROSCOPY | ? 32 |
| Water Content | %wt | AUTO TITRATION | ? 0.25 |
| Melting Point | ?C | KARL- FISHER | 255 ± 2 |
| Chip Weight | g/100EA | DSC | 2.2±0.1 |
| Property | Unit | Test | Value |
|---|---|---|---|
| Intrinsic Viscosity | dl/g | UBBELHODE | 0.64 ± 0.01 |
| DEG content | %wt | GC | 1.4 ± 0.4 |
| Color (CIE Lab) | L-value ,b-value | SPECTROSCOPY | ? 90;? 4.5 |
| Carboxyl End Group | mmol/kg | SPECTROSCOPY | ? 32 |
| Water Content | %wt | AUTO TITRATION | ? 0.25 |
| Melting Point | ?C | KARL- FISHER | 255 ± 2 |
| Titanium Dioxide | %wt | DSC | 0.34 ± 0.06 |
| Chip Weight | g/100EA | SPECTROSCOPY | 2.2±0.1 |
| Property | Unit | Test | Value |
|---|---|---|---|
| Intrinsic Viscosity | dl/gr | Ubbelhode | 0.64+ 0.01 |
| DEG content | %W | GC | 0.9-1.3 |
| Color(CIE LAB) | l-value | Spectroscopy | >90 |
| Carboxyl End Groups | mmol/kg | Auto Titration | <32 |
| Melting Point (DSC methode) | oC | DSC | 255+3 |
| Water content | wt% | Karl-Fisher | <0.25 |
| Chip | g/100EA | <0.25 |
| Property | Unit | Test | Value |
|---|---|---|---|
| Intrinsic Viscosity | dl/gr | Ubbelhode | 0.64+ 0.01 |
| DEG content | %W | GC | 0.9-1.3 |
| Color(CIE LAB) | l-value | Spectroscopy | >90 |
| Carboxyl End Groups | mmol/kg | Auto Titration | <32 |
| Melting Point (DSC methode) | oC | DSC | 255+3 |
| Titanium Dioxide content | wt% | Spectroscopy | 0.034+0.06 |
| Property | Unit | Test | Value |
|---|---|---|---|
| Intrinsic Viscosity(IV) | 0.82+0.02 | Ubbelhode | dl/gr |
| DEG Content | Max 2.0 | GC | %wt |
| Color(CIE Lab) | <2 | b | |
| Carboxyl End Group | Max 32 | AUTO TITRATION | meq/gr |
| Melting Point | 249±3 | DSC | ºC |
| Acetaldehyde (AA) | <1 | HEAD SPACE-GC | ppm |
| Water Content | <0.3 | KARL-FISHER | %wt |
| Property | Unit | Test | Value |
|---|---|---|---|
| Intrinsic Viscosity(IV) | 0.8+0.02 | Ubbelhode | dl/gr |
| DEG Content | Max1.5 | GC | %wt |
| Color(CIE Lab) | <2 | b | |
| Carboxyl End Group | Max 32 | ZIMMER WN-B010-7090E | meq/gr |
| Melting Point | 248+2 | ZIMMER WN-B010-7089E | ºC |
| Acetaldehyde (AA) | <1 | ZIMMER WN-B010-9013E | ppm |
| Water Content | <0.3 | ZIMMER WN-B010-7089E | %wt |
| Property | Unit | Test | Value |
|---|---|---|---|
| Intrinsic Viscosity(IV) | dl/gr | ZIMMER WN-B010-7040E | 0.84+0.02 |
| DEG Content | %wt | Max1.5 | |
| Color(CIE Lab) | L | ZIMMER WN-B010-7110E | >90 |
| Carboxyl End Group | meq/gr | ZIMMER WN-B010-7090E | Max 32 |
| Melting Point | ºc | ZIMMER WN-B010-7089E | 248+2 |
| Acetaldehyde (AA) | ppm | ZIMMER WN-B010-9013E | <1 |
| Water Content | %wt | ZIMMER WN-B010-7089E | <0.3 |
| Property | Unit | Test | Value |
|---|---|---|---|
| Intrinsic Viscosity(IV) | dl/gr | ZIMMER WN-B010-7040E | 0.82+0.02 |
| DEG Content | %wt | Max1.5 | |
| Color(CIE Lab) ZIMMER WN-B010-7110E | L | ZIMMER WN-B010-7110E | >90 |
| Carboxyl End Group | meq/gr | ZIMMER WN-B010-7090E | Max 32 |
| Melting Point | ºC | ZIMMER WN-B010-7089E | 248+2 |
| Acetaldehyde (AA) | ppm | ZIMMER WN-B010-9013E | <1 |
| Water Content | %wt | ZIMMER WN-B010-7089E | <0.3 |
| Property | Unit | Test | Value |
|---|---|---|---|
| Density | (g/ml) | 0.922 | ASTM D 1505 |
| MFR(190°C/2.16kg) | (g/10min) | 0.95 | ASTM D 1238 |
| Dart Impact | (g) | 80 | ASTM D 1709 |
| Elmendorf Tear MD/TD | (g) | 105/460 | ASTM D 1922 |
| Tensile strength at yield MD/TD | (MPa) | 13/12.5 | ASTM D 882 |
| Tensile strength at Break MD/TD | (MPa) | 45/30 | ASTM D 882 |
| Ultimate Elongation MD/TD | (%) | 680/780 | ASTM D 882 |
| 2% Secant modulus MD/TD | (MPa) | 200/240 | ASTM D 882 |
| Haze | (%) | 21 | ASTM D 1003 |
| Gloss 45° | (%) | 38 | ASTM D 2457 |
| DEG Content | %wt | Max1.5 | |
| Color(CIE Lab) | L | ZIMMER WN-B010-7110E | >90 |
| Carboxyl End Group | meq/gr | ZIMMER WN-B010-7090E | Max 32 |
| Melting Point | ºc | ZIMMER WN-B010-7089E | 248+2 |
| Acetaldehyde (AA) <0.3 ZIMMER WN-B010-7089E | ppm | ZIMMER WN-B010-9013E | <1 |
| Water Content | %wt | ZIMMER WN-B010-7089E | <0.3 |
| Property | Unit | Test | Value |
|---|---|---|---|
| Density | (g/ml) | ASTM D 1505 | 0.922 |
| MFR(190°C/2.16kg) | (g/10min) | ASTM D 1238 | 0.95 |
| Dart Impact | (g) | ASTM D 1709 | 80 |
| Elmendorf Tear MD/TD | (g) | ASTM D 1922 | 105/460 |
| Tensile strength at yield MD/TD | (MPa) | ASTM D 882 | 13/12.5 |
| Tensile strength at Break MD/TD | (MPa) | ASTM D 882 | 45/30 |
| Ultimate Elongation MD/TD | (%) | ASTM D 882 | 680/780 |
| 2% Secant modulus MD/TD | (MPa) | ASTM D 882 | 200/240 |
| Haze | (%) | ASTM D 1003 | 21 |
| Gloss 45° | (%) | ASTM D 2457 | 38 |
| Property | Unit | Test | Value |
|---|---|---|---|
| Melt Flow Rate(MFR) (190 °C/2.16Kg) (190 °C/5Kg) (190 °C/21.6Kg) | gr/10min | ASTM D 1238 | 2.3 |
| Density | gr/cm3 | ASTM D 1505 | 0.92 |
| Haze | % | ASTM D 1003 | 12 |
| Gloss(45°C) | % | ASTM D 2457 | 30 |
| Anti Oxidant | ? | ||
| Anti Block | ? | ||
| Slip Agent | ? | ||
| Dart Drop Impact | g | ASTM D 1709(A) | 90 |
| Tear Strength MD/TD | gr/25?m | ASTM D 1922 | 100/300 |
| Tensile Strength at yield MD/TD | MPa | ASTM D 882 | 10:11 |
| Tensile Strength at Break MD/TD | Mpa | ASTM D 882 | 30/25 |
| Elongation at break MD/TD | % | ASTM D 882 | 1000/1100 |
| Secant Modulus MD/TD | Mpa | ASTM D 882 | 80/100 |
| Coefficient of friction | ASTM D 1894 | 0.13 | |
| Vicat Softening Temperature | °C | ASTM D 1525 | 100 |
| Melting Point | °C | BPC | 123 |
| Property | Unit | Test | Value |
|---|---|---|---|
| Physical | 2.2 | ||
| Melt Flow Rate(MFR) (190 °C/2.16Kg) (190 °C/5Kg) (190 °C/21.6Kg) | g/10min | 0.92 | |
| Density | g/cm3 | ||
| Film Properties | 130 | ||
| Impact Strength | gr | ASTM D 1709 | 300 |
| Tear Strength TD | g/25? | ASTM D1922 | 110 |
| Tear Strength MD | g/25? | ASTM D1922 | 11 |
| Yield Stress TD | MPa | 10 | |
| Yield Stress MD | MPa | 28 | |
| Tensile Strength TD | MPa | 36 | |
| Tensile Strength MD | MPa | 800 | |
| Elongation at break TD | % | 600 | |
| Elongation at break MD | % | ||
| Modulus of elasticity TD | MPa | ||
| Modulus of elasticity TD | MPa | ||
| Thermal Properties | 93 | ||
| Vicat Softening Temperature | °C | ||
| Melting Point | °C |
| Property | Unit | Test | Value |
|---|---|---|---|
| Resin | |||
| MFI @ 190 °C,2.16 KG | G/10MIN | D 1238 | 0.9 |
| DENSITY | GR/CM3 | D2839 | 0.92 |
| VICAT SOFTENING POINT | °C | D1525 | 100 |
| FILM* | |||
| TENSILE STRENGHT @ YIELD,MD/TD | Mpa | D 638 | 10.5/11 |
| ELONGATION @BREAK ,MD/TD | % | D 638 | 620/840 |
| TENSILE STRENGTH @ BREAK ,MD/TD | Mpa | D 688 | 41/32 |
| TEAR STRENGTH ,MD/TD | gr/25mic | D 1922 | 145/370 |
| IMPACT STRENGTH ,DART | gr/25mic | D1709 | 150 |
| HAZE | % | D1003 | 10 |
| GLOSS(45°) | Rating | D2457 | 56 |
| Property | Unit | Test | Value |
|---|---|---|---|
| Resin | |||
| MFI @ 190 °C,2.16 KG | G/10MIN | D 1238 | 0.9 |
| DENSITY | GR/CM3 | D2839 | 0.92 |
| VICAT SOFTENING POINT | °C | D1525 | 100 |
| FILM* | |||
| TENSILE STRENGHT @ YIELD,MD/TD | Mpa | D 638 | 10.5/11 |
| ELONGATION @BREAK ,MD/TD | % | D 638 | 620/840 |
| TENSILE STRENGTH @ BREAK ,MD/TD | Mpa | D 688 | 41/32 |
| TEAR STRENGTH ,MD/TD | gr/25mic | D 1922 | 145/370 |
| IMPACT STRENGTH ,DART | gr/25mic | D1709 | 150 |
| HAZE | % | D1003 | 10 |
| GLOSS(45°) | Rating | D2457 | 56 |
| Property | Unit | Test | Value |
|---|---|---|---|
| Polymer Properties | |||
| Melt Flow Rate | dg/min | 0.3 | |
| Density | kg/m3 | 921 | |
| Optical Properties | |||
| Gloss (45?) | % | ASTM D 2457 | 46 |
| Haze | ` | ASTM D 1003A | 12 |
| Clarity | mV | SABTEC method | 65 |
| Mechanical Properties | |||
| Impact strength | kJ/m | ASTM D 4272 | 35 |
| Tear strength TD | kN/m | 25 | |
| Tear strength MD | kN/m | 20 | |
| Tensile test | |||
| Yield stress TD | Mpa | 11 | |
| Yield Stress MD | Mpa | 12 | |
| Tensile Stress at break TD | Mpa | 26 | |
| Tensile Stress at break MD | Mpa | 29 | |
| Strain at break TD | % | > 500 | |
| Strain at break MD | % | > 200 | |
| Modulus of elasticity TD | Mpa | 190 | |
| Modulus of elasticity MD | Mpa | 180 | |
| Coefficient of friction | ASTM D 1894 | 0.7 | |
| Blocking | g | < 5 | |
| Re-Blocking | g | 30 |
| Property | Unit | Test | Value |
|---|---|---|---|
| Melt Flow Rate ( 2.16kg) | 0.75 | ||
| Density | 923 | ||
| Tensile Moudlus | 260 | ||
| Tensile Strength at Yield | 11 | ||
| Tensile Strength at Break MD/TD | 26/20 | ||
| Tensile Strain at Break MD/TD | 300/600 | ||
| Dart Drop Impact (50 blown film) | 150 | ||
| Vicat softening temp (50ºC/h 10N) | 96 | ||
| Haze (50) | < 8.0 | ||
| Gloss (60º ,50) | > 90 |
| Property | Unit | Test | Value |
|---|---|---|---|
| Melt Flow Rate ( 2.16kg) | g/10 min | ISO 1133 | 4 |
| Density | Kg/m³ | ISO 1183 | 924 |
| Tensile Moudlus | MPa | ISO 527-1, -2 | 260 |
| Tensile Strength at Yield | MPa | ISO 527-1, -2 | 11 |
| Tensile Strength at Break MD/TD | MPa | ISO 527-1, -3 | 22/15 |
| Tensile Strain at Break MD/TD | % | ISO 527-1, -3 | 300/600 |
| Dart Drop Impact (50 blown film) | g | ASTM D 1709 | 100 |
| Vicat softening temp (50ºC/h 10N) | ºC | ISO 306 | 92 |
| Haze (50) | % | ASTM D1003 | < 8.0 |
| Gloss (60º ,50) | ASTM D2457 | > 105 |
| Property | Unit | Test | Value |
|---|---|---|---|
| Melt Flow Rate ( 2.16kg) | g/10 min | ISO 1133 | 1.9 |
| Density | Kg/m³ | ISO 1183 | 924 |
| Tensile Moudlus | MPa | ISO 527-1, -2 | 260 |
| Tensile Strength at Yield | MPa | ISO 527-1, -2 | 11 |
| Tensile Strength at Break MD/TD | MPa | ISO 527-1, -3 | 26/18 |
| Tensile Strain at Break MD/TD | % | ISO 527-1, -3 | 250/600 |
| Dart Drop Impact (50 blown film) | g | ASTM D 1709 | 110 |
| Vicat softening temp (50ºC/h 10N) | ºC | ISO 306 | 94 |
| Haze (50) | % | ASTM D1003 | < 8.0 |
| Gloss (60º ,50) | ASTM D2457 | > 100 |
| Property | Unit | Test | Value |
|---|---|---|---|
| Melt Flow Rate ( 2.16kg) | g/10 min | ISO 1133 | 0.25 |
| Density | Kg/m³ | ISO 1183 | 923 |
| Tensile Moudlus | MPa | ISO 527-1, -2 | 240 |
| Tensile Strength at Yield | MPa | ISO 527-1, -2 | 10 |
| Tensile Strength at Break MD/TD | MPa | ISO 527-1, -3 | 27/20 |
| Tensile Strain at Break MD/TD | % | ISO 527-1, -3 | 200/500 |
| Dart Drop Impact (50 blown film) | g | ASTM D 1709 | 250 |
| Vicat softening temp (50ºC/h 10N) | ºC | ISO 306 | 94 |
| Haze (50) | % | ASTM D1003 | < 14 |
| Gloss (60º ,50) | ASTM D2457 | > 50 |
| Property | Unit | Test | Value |
|---|---|---|---|
| MFI (190 0C /2 .16 Kg ) | dg/min | ISO 1183 (A) | ISO 1133 |
| Density | Kg/m3 | 4.7 | |
| Mechanical properties (2) | 920 | ||
| Impact strength | KJ/m | ASTM D 4272 | |
| Tear strength (TD) | KN/m | ISO 6383-2 | 15 |
| Tear Strength (MD) | KN/m | ISO 6383-2 | 25 |
| Yield stress (TD) | MPa | ISO 527 | 80 |
| Yield stress (MD) | MPa | ISO 527 | 11 |
| Tensile Stress at break (TD) | MPa | ISO 527 | 12 |
| Tensile Stress at break (MD) | MPa | ISO 527 | 15 |
| Strain at Break (TD) | % | ISO 527 | 27 |
| Strain at Break (MD) | % | ISO 527 | >500 |
| Modulus of Elasticity (TD) | MPa | ISO 527 | 100 |
| Modulus of Elasticity (MD) | MPa | ISO 527 | 200 |
| Coefficient of friction | ASTM D 1894 | 200 | |
| Blocking | g | SABTEC | 0.2 |
| Re-blocking | g | method | 20 |
| Optical properties (2) | SABTEC | 10 | |
| Haze | % | method | |
| Gloss(45o) | % | 9 | |
| Clarity | mV | ASTM D | 55 |
| Additive: Antioxidant , Slip agent, | 1003A | 21 | |
| Anti blocking agent | ASTM D 2457 |
| Property | Unit | Test | Value |
|---|---|---|---|
| MFI (190 0C /2 .16 Kg ) | ISO 1183 (A) | ISO 1133 | |
| Density | 2.5 | ||
| Mechanical properties | 921 | ||
| Impact strength | dg/min | ASTM D 4272 | |
| Tear strength (TD) | Kg/m3 | ISO 6383-2 | 23 |
| Tear Strength (MD) | ISO 6383-2 | 25 | |
| Yield stress (TD) | KJ/m | ISO 527 | 70 |
| Yield stress (MD) | KN/m | ISO 527 | 11 |
| Tensile Stress at break (TD) | KN/m | ISO 527 | 13 |
| Tensile Stress at break (MD) | MPa | ISO 527 | 19 |
| Strain at Break (TD) | MPa | ISO 527 | 30 |
| Strain at Break (MD) | MPa | ISO 527 | >500 |
| Modulus of Elasticity (TD) | MPa | ISO 527 | >100 |
| Modulus of Elasticity (MD) | % | ISO 527 | 180 |
| Coefficient of friction | % | 190 | |
| Blocking | MPa | SABTEC method | 0.2 |
| Re-blocking | MPa | SABTEC method | <5 |
| Optical properties | ASTM D 1894 | 0 | |
| Haze | g | ASTM D 1003A | |
| Gloss(45o) | g | ASTM D 2457 | 9 |
| Clarity | 60 | ||
| Additive: Antioxidant , Slip agent, Anti blocking | % | 30 | |
| agent | % |
| Property | Unit | Test | Value |
|---|---|---|---|
| MFI (190 0C /2 .16 Kg ) | dg/min | ISO 1133 | 1.9 |
| Density | Kg/m3 | ISO 1183 (A) | 921 |
| Mechanical properties (2) | |||
| Impact strength | KJ/m | ASTM D 4272 | 26 |
| Tear strength (TD) | KN/m | ISO 6383-2 | 25 |
| Tear Strength (MD) | KN/m | ISO 6383-2 | 60 |
| Yield stress (TD) | MPa | ISO 527 | 11 |
| Yield stress (MD) | MPa | ISO 527 | 13 |
| Tensile stress at break (TD) | MPa | ISO 527 | 20 |
| Tensile stress at break (MD) | MPa | ISO 527 | 35 |
| Strain at Break (TD) | % | ISO 527 | >500 |
| Strain at Break (MD) | % | ISO 527 | >150 |
| Modulus of Elasticity (TD) | MPa | ISO 527 | 200 |
| Modulus of Elasticity (MD) | MPa | ISO 527 | 190 |
| Coefficient of friction | ASTM D 1894 | >1 | |
| Blocking | g | SABTEC method | 20 |
| Re-blocking | g | SABTEC method | 100 |
| Optical properties (2) | |||
| Haze | % | ASTM D 1003A | 9 |
| Gloss (45o) | % | ASTM D 2457 | 55 |
| Clarity | mV | 26 | |
| Additive : Antioxidant |
| Property | Unit | Test | Value |
|---|---|---|---|
| MFI(190 0C /2 .16 Kg ) | Dg/min | ISO 1133 | 0.3 |
| Density | Kg/m3 | ISO 1183 (A) | 921 |
| Mechanical properties | |||
| mpact strength | KJ/m | ASTM D 4272 | 31 |
| Tear strength (TD) | KN/m | ISO 6383-2 | 45 |
| Tear Strength (MD) | KN/m | ISO 6383-2 | 20 |
| Yield stress (TD) | MPa | ISO 527 | 10 |
| Yield stress (MD) | MPa | ISO 527 | 11 |
| Tensile Stress at break (TD) | MPa | ISO 527 | 24 |
| Tensile Stress at break (MD) | MPa | ISO 527 | 22 |
| Strain at Break (TD) | % | ISO 527 | >500 |
| Strain at Break (MD) | % | ISO 527 | >350 |
| Modulus of Elasticity (TD) | MPa | ISO 527 | 150 |
| Modulus of Elasticity (MD) | MPa | ISO 527 | 140 |
| Coefficient of friction | ASTM D 1894 | 0.7 | |
| Blocking | g | SABTEC method | <5 |
| Re-blocking | g | SABTEC method | 20 |
| Optical properties | |||
| Haze | % | ASTM D 1003A | 12 |
| Gloss (45o ) | % | ASTM D 2457 | 55 |
| Clarity | mV | SABTEC method | 50 |
| Additive :Antioxidant |
| Property | Unit | Test | Value |
|---|---|---|---|
| Melt Flow Rate | dg/min | 1.9 | |
| Density | kg/m3 | ASTM D 2457 | 921 |
| Gloss (45?) | % | ASTM D 1003A | 50 |
| Haze | % | SABTEC method | 11 |
| Clarity | mV | ASTM D 4272 | 29 |
| Impact strength | kJ/m | 26 | |
| Tear strength TD | kN/m | 25 | |
| Tear strength MD | kN/m | 60 | |
| Yield stress TD | MPa | 11 | |
| Yield Stress MD | MPa | 13 | |
| Tensile Stress at break TD | MPa | 20 | |
| Tensile Stress at break MD | MPa | 29 | |
| Strain at break TD | % | > 500 | |
| Strain at break MD | % | > 150 | |
| Modulus of elasticity TD | MPa | 200 | |
| Modulus of elasticity MD | MPa | ASTM D 1894 | 190 |
| Coefficient of friction | > 1 | ||
| Blocking | g | 20 | |
| Re-Blocking | g | 100 |
| Property | Unit | Test | Value |
|---|---|---|---|
| Density | (g/cm³) | ASTM D 1505 | 0.938 |
| MFR(190°C/2.16kg) | (g/10min) | ASTM D 1238 | 4 |
| Flectural Modulus | Mpa | ASTM D 790 | 650 |
| Tensile Strenght at yield | Mpa | ASTM 638 | 15 |
| Tensile Strenght at break | % | ASTM 638 | 800 |
| Charpy Unnotched impact Strength | Kj/m² | ASTM D256 | 25 |
| Property | Unit | Test | Value |
|---|---|---|---|
| Density | g/cm3 | ISO 1183 | 0.937 |
| Melt Flow Rate(190 °C/2.16 kg) | dg/min | ISO 1133 | 0.1 |
| Melt Flow Rate(190 °C/21.6 kg) | dg/min | ISO 1133 | 13 |
| Tensile Modulus | MPa | ISO 527-1 | 735 |
| Tensile Strength(MD) | Mpa | ISO 527-1,3 | 46 |
| Tensile Strength(TD) | Mpa | ISO 527-1,3 | 46 |
| Tensile Strain at Break(MD) | % | ISO 527-1 | 550 |
| Tensile Strain at Break(TD) | % | ISO 527-1 | 650 |
| Elemendorf tear strength (MD) | Mn | ISO 6383-2 | 210 |
| Elemendorf tear strength (TD) | mN | ISO 6383-2 | 1100 |
| Vicat Temp,(A50,50°C/h,10N) | °C | ISO306 | 121 |
| Property | Unit | Test | Value |
|---|---|---|---|
| MELT FLOW INDEX(2.16KG) | 4 | ||
| DENSITY | 0.938 | ||
| TENSILE STRESS AT YEILD | 19 | ||
| ELONGATION AT BREAK | >1000 | ||
| FLEXURAL MODULUS | 650 | ||
| CHURPY IMPACT | 10 | ||
| HARDNESS | 62 | ||
| MELTING POINT | ASTM D-2117 | 127 | |
| VICAT SOFTENING POINT | 117 |
| Property | Unit | Test | Value |
|---|---|---|---|
| MFI@190°C, 5Kg | gr/10min | 53735 | 0.5 |
| Density | gr/cm3 | 53479 | 0.944 |
| Volatiles | %Wt | BP138 | 0.2 |
| Impact Strength(Charpy Index) | mj/mm2 | 53453 | 22 |
| Resistance to internal pressure | hr | 8074 | 170 min |
| (80°C/4N/mm2) |
| Property | Unit | Test | Value |
|---|---|---|---|
| Melt Flow Rate (190 ° C/5Kg) | g/10 min | 0.45 ± 0.05 | 0.45 ± 0.05 |
| Melt Flow Rate (190 ° C/21.6Kg) | g/10 min | 12.0 ± 3.0 | 12.0 ± 3.0 |
| FRR21.6/5 | ------ | 28 ± 4 | 28 ± 4 |
| Density | g/cm³ | 0.945 ± 0.002 | 0.945 ± 0.002 |
| Notched Impact Strength | mj/mm² | > 12 | > 12 |
| Pipe Evaluation Hydrostatic Strength (80 oc,4N/mm2) | hours | 1000 min | 1000 min |
| Property | Unit | Test | Value |
|---|---|---|---|
| Melt Index(21.6) | 9.5 | ISO 1113 | g/10 min |
| Melt Index(5) | 0.35 | ISO 1113 | g/10 min |
| FRR (21.6/5) | 27 | ||
| Density | 0.951 | ISO 1183 | g/cm³ |
| Swell Ratio | 110 | % | |
| Notched Impact @ 23 °C | 10 | ISO 179/ 1 eA | mJ/mm² |
| Property | Unit | Test | Value |
|---|---|---|---|
| Mass density (230C) | g/cm3 | D 1505 | 0.959 |
| Melt Flow Rate (190 ?C/2.16 kg) | g/10min | D 1238 | 0.35 |
| Izod impact strength | Kg.cm/cm | D 256 | 25 Min. |
| Yellow index | - | D 1925 | -5 Max. |
| Ash content | wt% | D 1063 | 0.06 Max. |
| Volatile matter | wt% | D 1960 | 0.05 Max. |
| Tensile strength @ break | gr/cm2 | D 638 | 290 Min. |
| Elongation @ break | % | D 638 | 900 Min. |
| Melting point | oC | D 2117 | 130 |
| Vicat softening point | oC | D 1525 | 126 |
| ESCR | hr | D 1693 | 15 |
| Property | Unit | Test | Value |
|---|---|---|---|
| MELT FLOW INDEX(2.16KG) | g/10miin | ASTM D-1238 | 2.2 |
| DENSITY | gr/cm3 | ASTM D-1505 | 0.952 |
| TENSILE STRESS AT YEILD | MPA | ASTM D-638 | 20 |
| ELONGATION AT BREAK | % | ASTM D-638 | 1100 |
| VICAT SOFTENING POINT | °C | ASTM D-1525 | 112 |
| YELLOW INDEX | #VALUE! | BP133 | -1 |
| WHITENESS INDEX | - | BP133 | 60 |
| CHARPY IMPACT | KJ/M2 | ASTM D-6110 | 15 |
| Property | Unit | Test | Value |
|---|---|---|---|
| Break Strength | Mpa | D638 | ?13 |
| Density | g/l | D1505 | 960±2 |
| Elongation at Break | % | D639 | 350 |
| Flexural Modulus | Mpa | D790 | ?1500 |
| Izod 23°C | j/m | D256/A | ?36 |
| MFR "E" | g/10 min | D1238 | 7.5±1 |
| Vicat | °C | D1525 | ?127 |
| Yield Strength | Mpa | D638 | ?30 |
| Property | Unit | Test | Value |
|---|---|---|---|
| Density | (g/ml) | ASTM D 1505 | 0.952 |
| MFR(190°C/2.16kg) | (g/10min) | ASTM D 1238 | 2 |
| Vicat Softening Point | º C | ASTM D 1525 | 124 |
| Flectural Modulus | MPa | ASTM D 790 | 1000 |
| Tensile Strenght at Yield | MPa | ASTM D 638 | 25 |
| Tensile Strenght at Break | MPa | ASTM D 638 | 38 |
| HDT | °C | ASTM D 648 | 78 |
| Notched Izod Impact @ 23 °C | J/m | ASTM D 256/A | 180 |
| Property | Unit | Test | Value |
|---|---|---|---|
| Density | (g/ml) | ASTM D 1505 | 0.957 |
| MFR(190°C/2.16kg) | (g/10min) | ASTM D 1238 | 5.5 |
| Vicat Softening Point | º C | ASTM D 1525 | 127 |
| Flectural Modulus | MPa | ASTM D 790 | 1480 |
| Tensile Strenght at Yield | MPa | ASTM D 638 | 30 |
| Tensile Strenght at Break | MPa | ASTM D 638 | 16 |
| H.D.T | º C | ASTM D 648 | 78 |
| Notched Izod Impact @ 23 °C | J/m | 46 |
| Property | Unit | Test | Value |
|---|---|---|---|
| Density | (g/ml) | ASTM D 1505 | 0.952 |
| MFR(190°C/2.16kg) | (g/10min) | ASTM D 1238 | 18 |
| Vicat Softening Point | º C | ASTM D 1525 | 122 |
| Flectural Modulus | MPa | ASTM D 790 | 1350 |
| Notched Izod Impact @ 23 °C | J/m | ASTM D 256/A | 25 |
| Property | Unit | Test | Value |
|---|---|---|---|
| Mass density (23ºC) | g/cm³ | ASTM D 1505 | 0.963-0.967 |
| Melt Flow Rate (190ºC/2.16kg) | g/10min | ASTM D 1238 | 04-Jun |
| Ash content | wt% | ASTM D 1063 | 0.06 max |
| Volatile matter | wt% | ASTM D 1960 | 0.05 max. |
| Tensile strength at break | gr/cm² | ASTM D 638 | 170 min |
| Elongation at break | % | ASTM D 638 | 300 min |
| Melting point | ºC | ASTM D 2117 | 130 |
| Vicat softening point | ºC | ASTM D 1525 | 124 |
| ESCR | hr | ASTM D 1693 | 4 |
| Property | Unit | Test | Value |
|---|---|---|---|
| Density | (g/ml) | ASTM D 1505 | 0.954 |
| MFR(190°C/2.16kg) | (g/10min) | ASTM D 1238 | 0.8 |
| Vicat Softening Point | º C | ASTM D 1525 | 125 |
| Flectural Modulus | MPa | ASTM D 790 | 1100 |
| Tensile Strenght at Yield | MPa | ASTM D 638 | 24 |
| Tensile Strenght at Break | MPa | ASTM D 638 | 39 |
| HDT | °C | ASTM D 648 | 75 |
| Notched Izod Impact @ 23 °C | J/m | ASTM D 256/A | 400 |
| Property | Unit | Test | Value |
|---|---|---|---|
| MELT FLOW INDEX(2.16KG) | g/10min | ASTM D-1238 | 3.7 |
| DENSITY | gr/cm3 | ASTM D-1505 | 0.96 |
| VICAT SOFTENING POINT | °C | ASTM D-1525 | 112 |
| TENSILE STRESS AT YEILD | MPA | ASTM D-638 | 20 |
| ELONGATION AT BREAK | % | ASTM D-638 | 700 |
| CHARPY IMPACT | KJ/M2 | ASTM D-6110 | 10 |
| WHITENESS INDEX | BP133 | 60 | |
| YELLOW INDEX | BP133 | -1 |
| Property | Unit | Test | Value |
|---|---|---|---|
| MELT FLOW INDEX(2.16KG) | g/10miin | 7 | |
| DENSITY | gr/cm3 | 0.96 | |
| TENSILE STRESS AT YEILD | MPA | 31 | |
| ELONGATION AT BREAK | % | 1000 | |
| FLEXURAL MODULUS | MPA | 1300 | |
| CHURPY IMPACT | KJ/M2 | 6 | |
| HARDNESS | - | 68 | |
| MELTING POINT | °C | ASTM D-2117 | 132 |
| VICAT SOFTENING POINT | °C | 127 | |
| SPECIFIC HEAT | J/KG°C | 2300 |
| Property | Unit | Test | Value |
|---|---|---|---|
| Melt Flow Rate(MFR) (190 °C/2.16 Kg) | g/10 min | ISO 1133 | 3.5 |
| Density | g/ml | ISO 1133 | 3.5 |
| MFR(190°C/5 kg) | g/10 min | ISO 1133 | 11 |
| FRR (5/2.16) | ISO 527 | 2.8 | |
| Fish Eye Note | (note) | internal | |
| Notched impact(23°C) | (mj/mm2) | ISO179/1eA | 4 |
| Hydrostatic Strength (4N/mm2 80°C) | h | ISO 1176 |
| Property | Unit | Test | Value |
|---|---|---|---|
| Melt Flow Rate(MFR) (190 °C/2.16 Kg)(190 °C/5 Kg) (190 °C/21.6 Kg) | g/10 min | ISO 1133 | 8 23-- |
| Density | g/cm3 | ISO 1183 | 0.957 |
| Tensile Strength@yield | Mpa | ISO 527 | 29 |
| Tensile Strength@break | Mpa | ISO 527 | 30 |
| Elongation @ break | % | ISO 527 | >1000 |
| Hardness Shore D | ISO 868 | 64 | |
| ESCR (FNCT)@2.5 Mpa | h | ISO CD 16770 | 1.5 |
| Charpy Notch Impact Strength | kj/m2 | ISO 179 | 3 |
| Vicat Softening Tempreature | °C | ISO 306 | 72 |
| Melting point | °C | ISO 3146 | 138 |
| Property | Unit | Test | Value |
|---|---|---|---|
| Density (23 °C) | g/cm3 | ISO 1183 | 0.952 |
| Melt Flow Rate(190 °C/2.16 kg) | g/10min | ASTM D1238 | 0.04 |
| Melt Flow Rate(190 °C/21.6 kg) | g/10min | ASTM D1238 | |
| Stress at Yield Point | kg/cm2 | ASTM D638 | 250 |
| Stress at break | kg/cm2 | ASTM D638 | 390 |
| Elongation at break | % | ASTM D638 | Above 500 |
| Izod impact | kg.cm/cm | ASTM D256 | 30 |
| Stress Cracking Resistance | hr | ASTM D1693 | Above600 |
| Melting point | °C | ASTM D2117 | 131 |
| Property | Unit | Test | Value |
|---|---|---|---|
| Density | g/cm3 | ISO 1183 | 0.951+/- 0.02 |
| Fish Eye Note | note | internal | <=3 |
| FRR 21.6/5 | 29+/-4 | ||
| MFR 190°/21.6 | g/10min | ISO1133 | 8+/-2 |
| MFR 190°/5 | g/10min | ISO1133 | 0.28+/-0.05 |
| Property | Unit | Test | Value |
|---|---|---|---|
| Density | g/cm3 | ISO 1183 | 0.95 |
| Melt Flow Rate(190 °C/21.6 kg) | dg/min | ISO 1133 | 10 |
| Tensile Modulus | Mpa | ISO 527-1 | 1050 |
| Tensile Strength(MD) | MPa | ISO 527-1,3 | 55 |
| Tensile Strength(TD) | Mpa | ISO 527-1,3 | 55 |
| Tensile Strain at Break(MD) | % | ISO 527-1 | 580 |
| Tensile Strain at Break(TD) | % | ISO 527-1 | 620 |
| Tensile Strain at Yield | Mpa | ISO 527-1 | 26 |
| Tensile Strain at Yield | % | ISO 527-1 | 10 |
| Elemendorf tear strength (MD) | mN | ISO 6383-2 | 250 |
| Elemendorf tear strength (TD) | Mn | ISO 6383-2 | 800 |
| Melting Point | °C | ISO 3146 | 132 |
| Vicat Temp,(A50,50°C/h,10N) | °C | ISO 306 | 127 |
| Property | Unit | Test | Value |
|---|---|---|---|
| K-value | - | DIN- 53726 | 65 |
| Sulphate ash | wt % max | DIN-53568/2 | 0.05 |
| Volatiles | wt % max | ISO R-1269 | 0.2 |
| Bulk density | gr/lit | DIN-53466 | 600 |
| Screen analysis (residue on sieve) > 63 micron >250 micron | wt % min wt % max | DIN-53734 DIN-53734 | 90 5 |
| Dark resin (particles in 250gr PVC) | No.max | HULS-6.7 | 30 |
| Plasticizer acceptance | grDOP/100grPVC min. | DIN-53417/1 | 10 |
| Fish eyes | number per 25 cm2 max. | HULS-6.9 | 5 |
| Flowability (dia. of funnel outlet) | mm max. | HULS-6.10 | 4 |
| Viscosity number | Cm3/gr | DIN- 53726 | 105 |
| Residual VCM | ppm | HULS-6.11 | ? 1 |
| Property | Unit | Test | Value |
|---|---|---|---|
| MFI (300 C) | ASTM D1238 | 10.1 – 12 | |
| Density | ASTM D792 | 1.2 | |
| Tensile Strength | ASTM D638 | ? 60 | |
| Modulus of Elasticity | ASTM D638 | 2000 – 2400 | |
| Elongation | ASTM D638 | > 90 | |
| Dielectric Strength | ASTM D149 | ? 20 | |
| Charpy Impact Strength | ASTM D6110 | ? 25 | |
| Vicat Soft. Temp. | ASTM D1525 | 142 – 147 | |
| Transmittance | ASTM D1003 | ? 80 | |
| Solvent Content | GC (int-st) | Max. 3000 |
| Property | Unit | Test | Value |
|---|---|---|---|
| MFI (300 C) | g/10 min | ASTM D1238 | 7.1 – 10 |
| Density | g/cm³ | ASTM D792 | 1.2 |
| Tensile Strength | Mpa | ASTM D638 | ? 60 |
| Modulus of Elasticity | Mpa | ASTM D638 | 2000 – 2400 |
| Elongation | % | ASTM D638 | > 90 |
| Dielectric Strength | Kv/mm | ASTM D149 | ? 20 |
| Charpy Impact Strength | Kj/m² | ASTM D6110 | ? 25 |
| Vicat Soft. Temp. | C | ASTM D1525 | 142 – 147 |
| Transmittance | % | ASTM D1003 | ? 80 |
| Solvent Content | ppm | GC (int-st) | Max. 3000 |
| Property | Unit | Test | Value |
|---|---|---|---|
| MFI (300 C) | g/10 min | ASTM D1238 | 4.1 – 7 |
| Density | g/cm³ | ASTM D792 | 1.2 |
| Tensile Strength | Mpa | ASTM D638 | ? 60 |
| Modulus of Elasticity | Mpa | ASTM D638 | 2000 – 2400 |
| Elongation | % | ASTM D638 | > 100 |
| Dielectric Strength | Kv/mm | ASTM D149 | ? 25 |
| Charpy Impact Strength | Kj/m² | ASTM D6110 | ? 20 |
| Vicat Soft. Temp. | C | ASTM D1525 | 143 – 147 |
| Transmittance | % | ASTM D1003 | ? 80 |
| Solvent Content | ppm | GC (int-st) | Max. 3000 |
| Property | Unit | Test | Value |
|---|---|---|---|
| Purity | %(w/w) | >99.8 | |
| Humidity | %(w/w) | <0.1 | |
| PH | 7.5-9.5 | ||
| Colour | Hazen(Pt-Co) | <20 | |
| Turbidity | NTU | <20 | |
| Size(below 80 mesh) | Mesh | 80% | |
| Solubility in H2O | 20ºC clear | ||
| Ash content | %(w/w) | <0.03 |
| Property | Unit | Test | Value |
|---|---|---|---|
| Izod impact (6.4 mm , notched) | Kj/m2 | D-256 | Min 33 |
| Melt flow index ( 220ºc , 10 kg) | gr/10 min | D-1238 | 04-Oct |
| Rock well hardness | R-scale | D-785 | 95-110 |
| HDT ( 1.82 m pa) | ?C | D-648 | Min 85 |
| Vicat softening Temp (5kg/50°c) | ?C | D-1525 | Min 94 |
| Tensile strength (23ºc , 50 mm/min) | Kg/cm2 | D-638 | Min 440 |
| Tensile elongation ( 23ºc , 50 mm/min) | % | D-638 | Min 25 |
| Flexural strength ( 23ºc , 2.8 mm/min) | Kg/cm2 | D-790 | Min 640 |
| Flexural Modulus ( 23ºc , 2.8 mm/min) | Kg/cm2 | D-790 | Min 20000 |
| Specific Gravity ( 23?C) | ........ | D-792 | 1.04 |
| Molding Shrinkage | % | D-955 | 0.4-0.7 |
| Flammability ( 1/8inch(3.2mm) ) | ........ | Ul94 | HB |
| Property | Unit | Test | Value |
|---|---|---|---|
| Izod impact (6.4 mm , notched) | Kj/m2 | D-256 | Min25 |
| Melt flow index ( 220ºc , 10 kg) | gr/10 min | D-1238 | Jul-14 |
| Rock well hardness | R-scale | D-785 | 100-120 |
| HDT ( 1.82 m pa) | ?C | D-648 | Min82 |
| Vicat softening Temp (5kg/50°c) | ?C | D-1525 | Min 94 |
| Tensile strength (23ºc , 50 mm/min) | Kg/cm2 | D-638 | Min 440 |
| Tensile elongation ( 23ºc , 50 mm/min) | % | D-638 | Min 16 |
| Flexural strength ( 23ºc , 2.8 mm/min) | Kg/cm2 | D-790 | Min 630 |
| Flexural Modulus ( 23ºc , 2.8 mm/min) | Kg/cm2 | D-790 | Min 18000 |
| Specific Gravity ( 23?C) | ........ | D-792 | 1.04 |
| Molding Shrinkage | % | D-955 | 0.4-0.7 |
| Flammability ( 1/8inch(3.2mm) ) | Ul94 | HB |
| Property | Unit | Test | Value |
|---|---|---|---|
| Izod impact (6.4 mm , notched) | Kj/m2 | D-256 | Min23 |
| Melt flow index ( 220ºc , 10 kg) | gr/10 min | D-1238 | Aug-16 |
| Rock well hardness | R-scale | D-785 | 100-120 |
| HDT ( 1.82 m pa) | ?C | D-648 | Min85 |
| Vicat softening Temp (5kg/50°c) | ?C | D-1525 | Min 96 |
| Tensile strength (23ºc , 50 mm/min) | Kg/cm2 | D-638 | Min 440 |
| Tensile elongation ( 23ºc , 50 mm/min) | % | D-638 | Min 18 |
| Flexural strength ( 23ºc , 2.8 mm/min) | Kg/cm2 | D-790 | Min 650 |
| Flexural Modulus ( 23ºc , 2.8 mm/min) | Kg/cm2 | D-790 | Min20000 |
| Specific Gravity ( 23?C) | ........ | D-792 | 1.04 |
| Molding Shrinkage | % | D-955 | 0.4-0.7 |
| Flammability ( 1/8inch(3.2mm) ) | ........ | Ul94 | HB |
| Property | Unit | Test | Value |
|---|---|---|---|
| Izod impact (6.4 mm , notched) | Kj/m2 | D-256 | Min19 |
| Melt flow index ( 220ºc , 10 kg) | gr/10 min | D-1238 | 29-39 |
| Rock well hardness | R-scale | D-785 | 95-115 |
| HDT ( 1.82 m pa) | ?C | D-648 | Min82 |
| Vicat softening Temp (5kg/50°c) | ?C | D-1525 | Min 93 |
| Tensile strength (23ºc , 50 mm/min) | Kg/cm2 | D-638 | Min 420 |
| Tensile elongation ( 23ºc , 50 mm/min) | % | D-638 | Min 16 |
| Flexural strength ( 23ºc , 2.8 mm/min) | Kg/cm2 | D-790 | Min 620 |
| Flexural Modulus ( 23ºc , 2.8 mm/min) | Kg/cm2 | D-790 | Min17000 |
| Specific Gravity ( 23?C) | ........ | D-792 | 1.04 |
| Molding Shrinkage | % | D-955 | 0.4-0.7 |
| Flammability ( 1/8inch(3.2mm) ) | ........ | Ul94 | HB |
| Property | Unit | Test | Value |
|---|---|---|---|
| Izod impact (6.4 mm , notched) | Kj/m2 | D-256 | D-256 |
| Melt flow index ( 220ºc , 10 kg) | gr/10 min | D-1238 | D-1238 |
| Rock well hardness | R-scale | D-785 | D-785 |
| HDT ( 1.82 m pa) | ?C | D-648 | D-648 |
| Vicat softening Temp (5kg/50°c) | ?C | D-1525 | D-1525 |
| Tensile strength (23ºc , 50 mm/min) | Kg/cm2 | D-638 | D-638 |
| Tensile elongation ( 23ºc , 50 mm/min) | % | D-638 | D-638 |
| Flexural strength ( 23ºc , 2.8 mm/min) | Kg/cm2 | D-790 | D-790 |
| Flexural Modulus ( 23ºc , 2.8 mm/min) | Kg/cm2 | D-790 | D-790 |
| Specific Gravity ( 23?C) | ........ | D-792 | D-792 |
| Molding Shrinkage | % | D-955 | D-955 |
| Flammability ( 1/8inch(3.2mm) ) | ........ | Ul94 |
| Property | Unit | Test | Value |
|---|---|---|---|
| Izod impact (6.4 mm , notched) | Kj/m2 | D-256 | 16-20 |
| Melt flow index ( 220ºc , 10 kg) | gr/10 min | D-1238 | Jun-14 |
| Melt flow index ( 200ºc , 5 kg) | gr/10 min | D-1238 | 0.9-1.5 |
| Rock well hardness | R-scale | D-785 | 100-120 |
| HDT ( 1.82 m pa) | ?C | D-648 | 91-93 |
| Vicat softening Temp (5kg/50°c) | ?C | D-1525 | 100-103 |
| Tensile strength (23ºc , 50 mm/min) | Kg/cm2 | D-638 | 440-460 |
| Tensile elongation ( 23ºc , 50 mm/min) | % | D-638 | 16-25 |
| Flexural strength ( 23ºc , 2.8 mm/min) | Kg/cm2 | D-790 | 630-650 |
| Flexural Modulus ( 23ºc , 2.8 mm/min) | Kg/cm2 | D-790 | 18000-21000 |
| Specific Gravity ( 23?C) | ........ | D-792 | 1.04 |
| Molding Shrinkage | % | D-955 | 0.4-0.7 |
| Flammability ( 1/8inch(3.2mm) ) | ........ | Ul94 | HB |
| Property | Unit | Test | Value |
|---|---|---|---|
| MELT FLOW INDEX(200°C-5KG) | GR/10miin | ASTM D-1238 | 1.8 |
| IZOD IMPACT STRENGTH | KGF.CM/CM | ASTM D-256 | 22 |
| VICAT SOFTENING POINT(5KGF LOAD) | °C | ASTM D-1525 | 98 |
| TENSILE STRENGTH AT YEILD | KGF/CM2 | ASTM D-638 (5mm/min) | 450 |
| FLEXURAL STRENGTH AT YEILD | KGF/CM2 | ASTM D-790 | 600 |
| FLEXURAL MODULUS | KGF/CM2 | ASTM D-790 | 22000 |
| ROCKWELL HARDNESS(AT 23°C) | R.SCALE | ASTM D-785 | 105 |
| Property | Unit | Test | Value |
|---|---|---|---|
| Appearance | visual | visual | clear light yellow liquid |
| Epoxy equivalent | g/eq | ASTM D1652 | 434-555 |
| Epoxy value | mol/100g | ASTM D1652 | 0.180-0.230 |
| Color | Pt-Co (APHA) | ASTM 1209(APHA) | Max 40 |
| Viscosity | Mpas | DIN 53015 @25°C | 6000-12000 |
| Hydrolysable Chlorine | %wt | ASTM 1726 | Max 0.1 |
| %Non-Volatile | %wt | DIN EN ISO 3251 | 74-76 |
| Property | Unit | Test | Value |
|---|---|---|---|
| Appearance | visual | visual | clear light yellow liquid |
| Epoxy equivalent | g/eq | ASTM D1652 | 434-555 |
| Epoxy value | mol/100g | ASTM D1652 | 0.180-0.230 |
| Color | Pt-Co (APHA) | ASTM 1209(APHA) | Max 100 |
| Viscosity | Mpas | DIN 53015 @25°C | 6000-12000 |
| Hydrolysable Chlorine | %wt | ASTM 1726 | Max 0.1 |
| %Non-Volatile | %wt | DIN EN ISO 3251 | 74-76 |
| Property | Unit | Test | Value |
|---|---|---|---|
| Appearance | visual | visual | clear light yellow liquid |
| Epoxy equivalent | g/eq | ASTM D1652 | 185-192 |
| Epoxy value | mol/100g | ASTM D1652 | 0.52-0.54 |
| Color | Pt-Co (APHA) | ASTM 1209 | Max 50 |
| Viscosity@25°C | Mpas | DIN 53015 | 10,000-14,000 |
| Hydrolysable Chlorine | %wt | ASTM 1726 | Max 0.1 |
| Non-Volatile | %wt | DIN EN ISO 3251 | Min 99.3 |
| Property | Unit | Test | Value |
|---|---|---|---|
| Appearance | visual | visual | clear light yellow liquid |
| Epoxy equivalent | g/eq | ASTM D1652 | 185-196 |
| Epoxy value | mol/100g | ASTM D1652 | 0.51-0.54 |
| Color | Pt-Co (APHA) | ASTM 1209(APHA) | Max 100 |
| Viscosity | Mpas | DIN 53015 (@25 C) | <15000 |
| Hydrolysable Chlorine | %wt | ASTM 1726 | Max 0.2 |
| Non-Volatile | %wt | DIN EN ISO 3251 | Min 99 |
| Property | Unit | Test | Value |
|---|---|---|---|
| Appearance | ASTM- D1722 | clear and free of suspended Matter | |
| purity(%) | ASTM-E346 | N/I | |
| water(wt%) | ASTM-E203 | 0.1 Max | |
| Ethanol (ppm wt) | ASTM-E346 | 10Max | |
| SP.GR@20/20 | ASTM -D 4052 | 0.7928 | |
| Acetone(ppm wt) | ASTM -D346 | 20 | |
| permanganate time@15c.minutes | ASTM-D1363 | 30 MINUTES | |
| Destillation Range | ASTM -D 1078 | Max 1.0'c to include 64.6'c±0.1 | |
| ACIDITY (ppm wt)as Acetic acid | ASTM-D1613 | 30 | |
| Total iron(ppm et) | ASTM-D1068 | N/I | |
| CHLORIDE(ppm wt) | ASTM-D512 | N/I | |
| SULFOHUR (ppm wt) | ASTM-D5623 | N/I | |
| Hydrocarbons(water Miscibility) | ASTM-D1722 | N/I | |
| Carbonisable PT-CO | ASTM-E346 | Blow 30 APHA | |
| Odour | ASTM-E1296 | characteristic no residual | |
| COLOR pt-co(APHA) | ASTM-D1209 | Blow 5 APHA | |
| Non volatile matter | ASTM1353 | 10Max | |
| TMA | ASTM-E346 | N/I | |
| Alkanity as NH (ppm wt) | ASTM-D1614 | N/I |
| Property | Unit | Test | Value |
|---|---|---|---|
| Appearance | clear,colorless | ||
| purity | 99.5% wt | ||
| Di Ethylene Glycol | 0.5%wt,max | ||
| Poly Ethylene Glycol | 0.1%wt,max | ||
| water | 0.05%wt,max | ||
| color(Pt-co) | 25max | ||
| Ash | 100mg/kg,max | ||
| SPECIFIC Gravity | 1.124-1.126,20/20 C | ||
| Boiling range at 0.1013 Mpa | |||
| 5%vol | 280 C,min | ||
| 5% vol | 295 C,max |
| Property | Unit | Test | Value |
|---|---|---|---|
| Purity(wt. %) | ASTM E-202 | Min 99.8 | |
| Water (wt%) | ASTM E-202 | Max 0.05 | |
| mono Ethylene Glycol | ASTM E-202 | Max 0.05 | |
| Tri Ethylene Glycol | ASTM E-202 | Max 0.05 | |
| Acidity as Acetic Acid(pmm) | ASTM D-1613 | Max 200 | |
| Ash (ppm) | ASTM D-254/A | Max 50 | |
| SP.GR.(20/20'C | ASTM D-891 | 1.1175-1.1195 | |
| COLOR(PT-CO) | ASTM D-1209 | Max 10 | |
| DISTILLATION @ 760 MM-HG | |||
| IBP(°C) | ASTM D-1078 | Min 242 | |
| DP(°C) | ASTM D-1078 | Max 250 |
| Property | Unit | Test | Value |
|---|---|---|---|
| Appearance | Colorless,transparent | ||
| Purity | 99.8%wt, min | ||
| Color(Pt-Co) | 5max | ||
| Diethylenen Glycol | 0.08%wt,max | ||
| Water | 0.08% wt,max | ||
| Specific Gravity | 1.1151-1.1156, 20/20 °C | ||
| Boiling /range at 0.1013 Mpa | |||
| 5% vol | 196°C, min | ||
| 95%vol | 199°C,max | ||
| Aldehyde (as formaldehyde) | 8mg/kg,max | ||
| Acidity (as acetic acid) | 10mg/kg,max | ||
| Iron (as Fe) | 0.1mg/kg,max | ||
| Inorganic chloride (asCI) | 0.05mg/kg,max | ||
| Ash | 50mg/kg,max | ||
| UV transmittance | |||
| 220 nm | 80%,min | ||
| 275 nm | 95%,min | ||
| 350 nm | 99%,min |
| Property | Unit | Test | Value |
|---|---|---|---|
| Molecular Formula | C2H4CI2 | ||
| Mol Wt | 98.96 | ||
| CAS# | [107-06-2] | ||
| Description | Clear colourless liquid | ||
| Purity (%) by GC | 99.90 min | ||
| Sp gravity @ 15/15 deg cel | 1.248-1.250 | ||
| Distillation Range in deg cel | 81-85 at 760 mm Hg | ||
| Moisture (%) | 0.03% max | ||
| Free chlorine in ppm | Report | ||
| Acidity as HCI | Report | ||
| ROE | Report | ||
| Flash point in deg cel | 13 |
| Property | Unit | Test | Value |
|---|---|---|---|
| Molecular formula | NaOH | ||
| Mol Wt | 39.99 | ||
| CAS# | [1310-73-2] | ||
| Density in g ml at 20/20 deg cel | 0.9300-0.9400 | ||
| Sodium hydroxide as NaOH(%) | 47.0 min | ||
| Sodium carbonate as Na2CO3(%) | 0.40max | ||
| Sodium chloride as NaCI(%) | 0.1max | ||
| Iron in ppm | report |
| Property | Unit | Test | Value |
|---|---|---|---|
| Appearance | MAP-SM111 | Clear ;Free From Matter Suspension | |
| Purity (WT%) | MAP-70014 | Min 99.85 | |
| Water (WT%) | ASTM-D1364 | Max 0.15 | |
| Formic ACID (ppm wt) | ASTM-D3546 | Max 500 | |
| Density @ 20 CKg/Lit | ASTM-D1298 | 1.048-1.051 | |
| Acetaldehyde(ppm wt) | ASTM -D2191 | Max 200 | |
| permanganate time@20c,hours | MAP - 70019 | Minimum 2 Hours | |
| Crystallization point | ASTM-D1493 | 16.35 'C Min | |
| Sulphates (as SO4) | MAP- 70021 | Max 1 PPM | |
| Chloride (as CL) | MAP-70020 | Max 1 PPM | |
| Total Iron (ppm) | ASTM-E394 | Max 1.0 | |
| propionic Acid (ppm wt) | M602.515 | Max 50 | |
| Non Volatile Matter (ppm wt) | ASTM-D1353 | Max30 |
| Property | Unit | Test | Value |
|---|---|---|---|
| HAB | Wt% | 65-90 | |
| IBP | °C | 290 min | |
| FBP | °C | 510 max | |
| Appearance | light yellow to light brown liquid light yellow to light brown liquid | ||
| WATER | ppm | 100 max | |
| DENSITY (15.6 °C) | gr/cm3 | 0.895 max | |
| Dr TEST | Negative | ||
| FLASH POINT | °C | 170 min | |
| COLOUR | SYB | 2 max | |
| Viscoslty(40°C) | MM2/S | 16-50 |
| Property | Unit | Test | Value |
|---|---|---|---|
| DENSITY at 15.6 °c | ASTM D-4052-96 | 0.8575-0.8700 | |
| say bolt color | ASTM D-156-00 | Min 29 | |
| Bromin index ,mg Br/100 gr of sample | ASTM D- 1492-87 | Max 15 | |
| Moisture(ppm) | UOP 481-91 | Max 200 | |
| Refractive index at 20 °c | ASTM D-1218-99 | 1.480-1.490 | |
| Normal Parrafin (wt %) | UOP 698-93 | Max 0.5 | |
| 2-Phenyl Alkanes(wt.%) | UOP 698-93 | Max 200 | |
| Linear Alkyl Benzene (wt.%) | UOP 698-93 | Min 92 | |
| Carbon Distribution (Non Normalized) | UOP 698-93 | ||
| Max 1 | | ||
| LAB 10 | Max 15 | ||
| LAB 10 +LAB 11 | 33-51 | ||
| LAB12 | 22-34 | ||
| LAB13+LAB14 | 15-28 | ||
| LAB14 | Max 1 | ||
| >LAB 14 | Max 0.5 | ||
| Average Molecular Weight | UOP 698-93 | 238-244 |
| Property | Unit | Test | Value |
|---|---|---|---|
| Molecular Formula | C8H8 | ||
| Mol Wt | 104.14 | ||
| CAS# | [100-42-5] | ||
| Description | clear colorless liquid | ||
| purity(%) | 99.5 min | ||
| Aldehydes as benzenaldehyde(%) | 0.02 max | ||
| peroxides as H@O@ in ppm | 100 max | ||
| inhibitor in ppm | 10_15 |
| Property | Unit | Test | Value |
|---|---|---|---|
| Purity wt. % | ASTM D 2360-82 | 99.90 min | |
| Non aromatics wt. % | ASTM D 2360-82 | 0.10 max | |
| Toluene wt. % | ASTM D 2360-82 | 0.05 max | |
| Distillation range `c at 760 mm Hg | ASTM D 85079 | 1.0 max includeing 80.1 | |
| Appearance | VISUAL | Clear liquid free of sedimentation or haze at 18.3 to 25.6 `c | |
| Total Sulfur wt. ppm | ASTM D 4045-87 | 1.0 max | |
| Copper corrosion | ASTM D 849-88 | Pass (1a to 1b) | |
| Color, Pt-co scale | ASTM D 1209-84 | 20 max | |
| Acid wash color | ASTM D 848-81 | Pass with 1 | |
| Acidity | ASTM D 847-87 | None detected | |
| Specific Gravity at 15.56/15.56 `c | ASTM D 4052-86 | 0.882 - 0.886 | |
| SO2 / H2S | ASTM D 853-82 | None detected | |
| Solidification Point `c | ASTM D 852-87 | 5.45 min | |
| Thiophene wt.ppm | ASTM D 5623-94 | 0.60 max | |
| Vapor Pressure psi | ASTM D 323-99A | 3.3 |
| Property | Unit | Test | Value |
|---|---|---|---|
| Density @ 15deg.c,kg/m3 | ASTM D 4052 | 830 max | |
| P-Xylene, percent by Mass | ASTM D 2306 | 18.0 min | |
| Ethyl Benzene,percent by mass | ASTM D 2306 | 20.0 max | |
| Toluene,percent by mass | ASTM D 2360 | 0.5 max | |
| C9 and Higher Boiling aromatic Hydrocarbonc,percent by mass | |||
| Non Aromatics Hydrocarboin,percent by mass | ASTM D 2360 | 2.0 max | |
| Nitrogen mg/kg | UOP 313 | 1.0 max | |
| Sulfur mg/kg | UOP 357/D 3220/IP373 | 1.0 max | |
| Color,Pt/Co scale | ASTM D 1209 | 20.0 max | |
| Distillation | ASTM D 850 | ||
| 1) IBP,°C | 135 min | ||
| 2) Dry point,°c | 143 max | ||
| 3) Distillation Range, °C | 5 | ||
| Bromin index,mg/100g | ASTM D 5776 | 20 MAX |
| Property | Unit | Test | Value |
|---|---|---|---|
| Purity wt% | UOP 744-86 | 98.0 min (expected value:99) | |
| Non - Aromatics wt% | ASTM D2360-00 | 0.5 Max | |
| Bzn+C9 & Heavier Aromatics wt% | UOP 744-86 | 1.0 Max | |
| Ortho,Meta & Para Xylene plus Toulene pus Ethylbenzene wt% | UOP 744-86 | 98.5 Min | |
| Distillation range 'c at 760 mm Hg | ASTM D 850-00 | 2.0 Max including 144.4 | |
| Total Sulfur wt.pm | ASTM D 4045-99 | 1.0 Max | |
| Color, Pt-co scale | ASTM D 1209-00 | 20.Max | |
| Acidity | ASTM D 847-96 | None detected | |
| Hydrocarbon residue after evaporation wt.ppm | ASTM D 1353-96 | 20 Max | |
| SO2 / H2S | ASTM D 853-97 | None detected | |
| Vapor Pressure psi | ASTM D 323-99A | 0.3 |
| Property | Unit | Test | Value |
|---|---|---|---|
| purity wt.% | ASTM D 3798-00 | 99.7 min | |
| Non aromatics wt. % | ASTM D 3798-00 | 0.1max | |
| m-Xylene wt.% | ASTM D 3798-00 | 0.2max | |
| 0-Xylene wt.% | ASTM D 3798-00 | 0.1max | |
| Ethylbenzene wt.% | ASTM D 3798-00 | 0.3max | |
| Toluene wt. % | ASTM D 3798-00 | 0.1max | |
| appearance | VISUAL | Clear liquid free of sedimentation or haze at 18.3to 25.6 'c | |
| color,Pt-co scale | ASTM D 1209-00 | 20 max | |
| Distillation range 'c at 760 mm Hg | ASTM D 850-00 | 20 max including 138.3 | |
| Total Sulfour wt. ppm | ASTM D 4045-99 | 1.0 max | |
| Specific Gravity at 15.56/15.56 'c | ASTM D 4052-96 | 0.865-0.867 | |
| Vapor Pressure Psi | ASTM D 323-99A | 0.3 |
| Property | Unit | Test | Value |
|---|---|---|---|
| Purity wt% | ASTM D2360-00 | 99.9 min (expected value:99.98) | |
| Non Aromatics wt % | ASTM D2360-00 | 0.1 max | |
| Benzene wt % | ASTM D2360-00 | 0.03 max | |
| Distillation rang' c at 760 mmHg | ASTM D850-00 | 1.0 max including 110.6 | |
| Appearance | Visual | clear liquid free of sedimentation or haz at 18.3 to 25.6'c | |
| Total Sulfur wt.ppm | ASTM D4045-99 | 1.0 max | |
| Copper corrosion | ASTM D849-97 | Pass(1a to 1b) | |
| Color, Pt-co scale | ASTM D1209-00 | 20max | |
| Acid wash color | ASTM D 848-97 | 2max | |
| Acidity | ASTM D 847-96 | Non detected | |
| Specific Gravity at 15.56/15.56 'c | ASTM D4052-96 | 0.869-0.873 | |
| SO2/H2S | ASTM D 853-97 | Non detected | |
| Vapor Pressure psi | ASTM D 323-99A | 1.1 |
| Property | Unit | Test | Value |
|---|---|---|---|
| NITROGEN CONTENT (WT %) MIN | 46 | ||
| MOISTURE (WT %) MAX | 0.50 | ||
| BIURET CONTENT (WT %) MAX. | 1.00 | ||
| FORMALDEHYDE (WT %) MAX. | 0.55 | ||
| IRON (PPM) MAX | 1.00 | ||
| FREE NH3 (PPM) MAX. | 150 | ||
| CRUSHING STRENGTH (KG) MIN. DIAMETER: 3.15 MM | 3.00 | ||
| PARTICLE SIZE: 90% MINIMUM | 2.4mm |
| Property | Unit | Test | Value |
|---|---|---|---|
| Molecular Formula | NH3 | ||
| Mol Wt | 17 | ||
| CAS# | [82-0-0] | ||
| Description | Liquid Below (-) 33 deg cel Gas Abov (-) 33 Deg cel | ||
| Amonia (%NH3) | 99.5 Min | ||
| Total Nitrogen(Wt %N) | 82 min | ||
| Moisture(%) | 1max | ||
| oil in ppm | 20 max |
| Property | Unit | Test | Value |
|---|---|---|---|
| PURITY (ON DRY BASIS) (WT%) MIN | BS-4113 | 99.5 | |
| ASH CONTENT (WT %) MAX | BS-4113 | 0.05 | |
| MOISTURE (WT%) MAX | BS-4113 | 0.5 | |
| HYDROCARBONS (WT%) MAX | BS-4113 | 0.05 | |
| ACIDITY (AS H2SO4) WT% | ISO 3704 | MAX 0.02 | |
| BULK DENSITY KG/M3 | ASTM D-1895 | MAX 1240 | |
| COLOR | VISUAL | BRIGHT YELLOW | |
| MESH SIZE | 2-6 MM | ISO 8397 | MIN 90% |
| Property | Unit | Test | Value |
|---|---|---|---|
| 1,3-Butadiene | wt ppm | MTM 15787 E | 6 |
| 1-BUTENE | Mol% | MTM 15787 E | 99.846 |
| ACETYLENE | wt ppm | MTM 151015 | <1 |
| C6+ | wt ppm | MTM 15787 E | 83 |
| Cis-2-Butene | wt ppm | MTM 15787 E | 17 |
| CO | ppm | MTM 151003 | <0.01 |
| CO2 | ppm | MA 16330 | <0.1 |
| Ethane | wt ppm | MTM 15787 E | <1 |
| Ethylene | wt ppm | MTM 15787 E | <1 |
| METHANOL | wt ppm | MTM 151014 | <0.1 |
| n-Butane | wt ppm | MTM 15787 E | 1385 |
| TOTAL SULPHUR | ppm | ASTM D5453 | <0.3 |
| trans-2-Butene | wt ppm | MTM 15787E | 45 |
| WATER | ppm | MA 15042 | 0.8 |
| Property | Unit | Test | Value |
|---|---|---|---|
| SP.GR.@60?F | ASTM D2598 | to be reported | |
| Propane Content(Vol%) | ASTM D2163 | 96 min | |
| Ethane Content | ASTM D2163 | 2 max | |
| Vap.Pressure@100F(psig) | ASTM D1267 or D2598 | 200 max | |
| Volatile residue: C4 & heavier (vol %) | ASTM D2163(1) | 2.5 max | |
| Residual Matter: Resid.on evap.of 100ml(ml) | ASTM D2158 | 0.05 max | |
| Residual Matter: oll stain observation(ml) | ASTM D2158 | Pass(2) | |
| Corrosion Copper Strip | ASTM D1838 or D5453 | No.1 Strip | |
| Sulphur Content (WT%) | ASTM D1266 | 0.04 max | |
| Hydrogen Sulphide | ASTM D2420 or IP103 | Negative | |
| Moisture Content | ASTM D2713 or D1744 | Pass |
| Property | Unit | Test | Value |
|---|---|---|---|
| SP.GR.@60?F | ASTM D2598 | to be reported | |
| Butane Content(Vol%) | ASTM D2163 | 95 | |
| Vap.Pressure@100F(psig) | ASTM D1267 or D2598 | 70 max | |
| Volatile residue: C5 & heavier (Vol%) | ASTM D2163(1) | 2 max | |
| Corrosion Copper Strip | ASTM D1838 | No.1 Strip | |
| Sulphur Content(WT%) | ASTM D1266 or D5453 or IP 103 | 0.008 | |
| Hydrogen Sulphide | ASTM D2420 | Negative | |
| Free Water | VISUAL | None |
| Property | Unit | Test | Value |
|---|---|---|---|
| purity(1) | wt% | 99.5 min | |
| propadiene | ppm,wt | 10 max. | |
| 1,2 Butadiene | ppm,wt | 20 max. | |
| Total acetylene | ppm,wt | 20 max. | |
| Methyl acetylene | ppm,wt | Report | |
| Ethyl acetylene | ppm,wt | Report | |
| Vinyl acetylene | ppm,wt | Report | |
| Butene-1/isobutylenes | - | Report | |
| Cis butene 2 | - | Report | |
| trans butene-2 | - | Report | |
| Total C5's | ppm,wt | 500max. | |
| Sulfur(as H25) | ppm,wt | 5max. | |
| Carbonyls (as CH3CHO) | ppm,wt | 10max | |
| Peroxides(asH202) | ppm,wt | 5max. | |
| TBC(ter6tiary butyl catgechol) | ppm,wt | 75-150 | |
| Butadiene dimer | ppm,wt | 250max. | |
| total atomic Nitrogen(2) | ppm,wt | 300max. | |
| solvency (n-methyl -2-pyrrolidone(NMP) | ppm,wt | 5max. | |
| Oxygen in vapors(3) | vol% | 0.1max. |
| Property | Unit | Test | Value |
|---|---|---|---|
| I.B.P | °C | ASTM D86 | 75-90 |
| 10% | °C | ASTM D86 | 90-100 |
| 50% | °C | ASTM D86 | 100-120 |
| 90% | °C | ASTM D86 | 130-145 |
| F.B.P | °C | ASTM D86 | 145-160 |
| Density @ 15.6 °C | gr/cm3 | ASTM D 4052 | TO BE REPORTED |
| R.V.P | psi | ASTM D 323 | <5 |
| Color(Pt-Co) Scale | - | ASTM D 1209 | <3 |
| Total sulfur | wt ppm | ASTM D 5453 | <1 |
| Doctor Test | - | ASTM D 4952 | Negative |
| BZ | Wt% | IFP 9301 | <5 |
| Property | Unit | Test | Value |
|---|---|---|---|
| IBP | –C | ASTM-D86 | |
| FBP | –C | ASTM-D86 | |
| RONC | - | D-2699 | |
| Total Sulfur | wt ppm | D-5453 | |
| Lead Content | wt ppb | ||
| Benzene | wt% | GC | |
| Toluene | wt% | GC | |
| C8 Aromatics | wt% | GC | |
| C9 Aromatics | wt% | GC | |
| Total Aromatics (6-9 Carbon) | wt% | GC | |
| Total Non Aromatics (5-9 Carbon) | wt% | GC | |
| C10+ | wt% | GC | |
| Density | gr/cm3 | D-4052 | |
| RVP | Psi | D-323 |
| Property | Unit | Test | Value |
|---|---|---|---|
| DENSITY AT 15.6 °C (60°F ) | gr/cm3 | D-4052 | 0.9 MAX |
| TOTAL SULFUR | ppm | D-5453 | 200 MAX |
| R.V.P | Psi | D-323 | 5 MAX |
| IBP | °C | D-86 | 40 MIN |
| 5 PCT VOL RECOVERED | °C | D-86 | 60 MIN |
| 95 PCT VOL RECOVERED | °C | D-86 | 200 MAX |
| FBP | °C | D-86 | 210 MAX |
| PARAFFINS | WT% | G.C | MAX 3 |
| OLEFINS | WT% | G.C | MAX 30 |
| NAPHTHENES | WT% | G.C | MAX 0.6 |
| AROMATICS | WT% | G.C | 60 MIN |
| OTHERS | WT% | G.C | 20 MAX |
| BENZEN CONTENT | WT% | G.C | 40 MIN |
| Property | Unit | Test | Value |
|---|---|---|---|
| Density | 0.715-0.780 | ||
| Color Saybolt | +30 | ||
| RVP@F Kg/cm2 | 0.08-.010 | ||
| Sulfur | 0.33-0.49 | ||
| Distillation (Deg C) | |||
| IBP | 95-98 | ||
| 10% | 104-106 | ||
| 50% | 115-117 | ||
| 90% | 140-144 | ||
| FBP | 164-167 | ||
| Nitrogen | <0.5 | ||
| Lead | |||
| Paraffins | 48.97-49.74 | ||
| Olefins | |||
| Naphthene | 34.89-35.45 | ||
| Aromatics | 15.37-15.78 | ||
| Benzene | 0.2-0.3 |
| Property | Unit | Test | Value |
|---|---|---|---|
| RVP | Psia | ASTM D323 | Max 11 |
| IBP | °c | ASTM D 86 | Min 30 |
| FBP | °c | ASTM D 86 | Max 130 |
| PARAFFINIC | wt.% | Min 70 | |
| OLEFINIC | wt.% | ASTM D 4052 | Max 14 |
| DENSITY @ 15.6 °C | kg/m3 | ASTM D 4045 | 650-740 |
| TOTAL SULFUR | ppm | ASTM D 156 | Max 1.5 |
| COLOR SAYBOLT | GF AAS | Min +18 | |
| LEAD | ppb | Max |
| Property | Unit | Test | Value |
|---|---|---|---|
| Iso & Normal Butane | Mol% | G.C | 28 max |
| 1-Butene | Mol% | G.C | 25 max |
| Iso-Butene | Mol% | G.C | 45 min |
| Trans & Cis butane-2 | Mol% | G.C | 22 max |
| 1,2 & 1,3 Butadiene | Mol% | G.C | 1 max |
| Methyl Acetylene | Mol% | G.C | 0.5 max |
| Vinyl Acetylene | Mol% | G.C | 0.2 max |
| Ethyl Acetylene | Mol% | G.C | 0.2 max |
| Sp.Gr@(15.6 oC) | ASTM D-2598 | ||
| Total Sulphur | Wt.ppm | Microcoulometry | 1 max |
| Copper Corrosion | ASTM D-1838 | No.1a | |
| C3 & Lighter HC | Mol% | G.C | 0.05 max |
| C5 & Heavier HC | Mol% | G.C | 0.1 max |
| R.V.P @ (100oF) | Psia | ASTM D-1267 | 70 max |
| R.V.P @ (100oF) | Psia | ASTM D-1267 | 70 max |
| Evaporated Temp, 95% | Oc | ASTM D-1837 | #NAME? |
| Residue on Evaporation | Vol% | ASTM D-2158 | 0.05 max |
| Water Content | Wt.ppm | Evaporation Method | 700 max |
| Property | Unit | Test | Value |
|---|---|---|---|
| OENSITY@ 15' C | Kg/m3 | D1298 D4052 | 720min -750max |
| RESEARCH OCTANE NUMBER PREMIUM | 2699 | 95min | |
| MOTOR OCTANE NUMBER PREMIUM | D2700 | 85min | |
| REID VAPOR PRESSURE SUMMER WINTER | KPA | D23 | |
| SUMMER | D23 | 60max | |
| WINTER | D23 | 70max | |
| DESTILLATION | %V/V | D86 | |
| INITIAL BOILING POINT | %V/V | D86 | |
| EVAPORATED 100 'C | %V/V | D86 | |
| EVAPORATED 150 'C | %V/V | D86 | |
| FINAL BOILING POINT | |||
| HYDROCARBON ANALYSIS | %V/V | D1319 | 18max |
| OLEFINS | %V/V | D1319 | 35max |
| AROMATICS | %V/V | D2267 | 1max |
| BENZENE | %V/V | D2267 | |
| OXYGEN CONTENT | %M/M | 2.7max | |
| ALCOHOL | %V/V | ZEROmax | |
| ETHERS CONTAINING 5 OR MORE CARBON PER MOLECULE | %V/V | 15max | |
| SULPHUR | PPM | 50max | |
| LEAD CONTENT | g/l | ||
| EXISTENT GUM (WASHED) | Mg/(100mI) | 4max | |
| COOPER COROSION (3HRS AT 50 'C) | SCALE | CLASS I | |
| INDUCTION PERIOD AT 100 'C | Minutes | ||
| COLOR GREEN | Mg/I | 1max |
| Property | Unit | Test | Value |
|---|---|---|---|
| Distillation Range | °C | ASTMD86 | |
| IBP | °C | ASTMD86 | 165-180 |
| 10% | °C | ASTMD86 | 180-192 |
| 30% | °C | ASTMD86 | 192-209 |
| 50% | °C | ASTMD86 | 215-230 |
| 90% | °C | ASTMD86 | 295-330 |
| FBP | °C | ASTMD86 | 348-370 |
| Total Recovery | % | ASTMD86 | 96 |
| Total Sulfur | ppm | ASTMD5453 | Max 2000 |
| Color | ASTMD1500 | Max 2 | |
| Flash Point | °C | ASTMD93 | Min 60 |
| Specific Gravity | ASTMD4052 | 0.77-0.83 |
| Property | Unit | Test | Value |
|---|---|---|---|
| Density @ 15°C | Kg/m3 | ASTM D1298 | |
| Distillation: Recovered @ 150°C Recovered @ 300°C Recovered @ 357°C | |||
| F.B.P | Vol% | ASTM D86 | |
| Colour | °C | ASTM D86 | |
| Flash point | - | ASTM D1500 | |
| Sulphur Total | °C | ASTM D93 | |
| Corrosion-3hrs@100°C | wt% | ASTM D1552 | |
| Viscosity Kinematic@37.8°C | - | ASTM D130 | |
| Cloud point | c.St | ASTM D445 | |
| Pour point | °C | ASTM D2500 | |
| Carbon Residue ( on 10 % Bottoms) | °C | ASTM D97 | |
| Ash | wt% | ASTM D189 | |
| Water & Sediment | wt% | ASTM D482 | |
| Cetane Index | Vol% | ASTM D2709 |
| Property | Unit | Test | Value |
|---|---|---|---|
| Density @ 15°C | Kg/m3 | ASTM D1298 | 820-860 |
| Distillation: Recovered @ 150°C Recovered @ 300°C Recovered @ 357°C | Vol% | ASTM D86 | |
| F.B.P | °C | ASTM D86 | 385 max |
| Colour | ASTM D1500 | 3 max | |
| Flash point | °C | ASTM D93 | 54 min |
| Sulphur Total | wt% | ASTM D1552 | 1 max |
| Corrosion-3hrs@100°C | ASTM D130 | 1a | |
| Viscosity Kinematic@37.8°C | c.St | ASTM D445 | 2.0-2.5 |
| Cloud point | °C | ASTM D2500 | 2.0 max |
| Pour point | °C | ASTM D97 | - 3.0 max |
| Carbon Residue ( on 10 % Bottoms) | wt% | ASTM D189 | 0.1 max |
| Ash | wt% | ASTM D482 | 0.01 max |
| Water & Sediment | Vol% | ASTM D2709 | 0.05 max |
| Cetane Index | ASTM D976 | 50 min |
| Property | Unit | Test | Value |
|---|---|---|---|
| Kinematic Viscosity at 100deg C ,mm 2/sec | GOST33 | 6.85 | |
| Viscosity Index , min | GOST 25371 | 98 | |
| Cokeabillty, %, max | GOST19932 | 0. 011 | |
| Acid Index, Mg KOH/1 g oil,max | GOST 5985 | 0.0048 | |
| Ash, %, max | GOST1461 | 0.003 | |
| Content of water- soluble acids and alkalines | GOST6307 | NIL/OTCYTCTBYET | |
| Mass content of meconanical impurities | GOST6370 | NIL/OTCYTCTBYET | |
| Content of water , mass % | GOST 2477 | TRACES/cn. | |
| Flash point in open cup, deg C, min | GOST 4333 | 221 | |
| Pour point , deg , max | GOST 20267, method B | - 15 (FLOWS/AB.) | |
| Colour on colorimeter CNT , CNT Unit, max | GOST 20254 | 1.5 | |
| Content of sulphur,% ,max | GOST 1437 | 0.11 | |
| Content of selective solvents | GOST 1057 or 1520 | NIL/OTCYTCTBYET | |
| Density at 20 deg C ,kg/m3, max | GOST 3900 | 873.5 |
| Property | Unit | Test | Value |
|---|---|---|---|
| SP.GR@60/60 OF app | 0.886 | ||
| FLASH POINT c (min) | 220 | ||
| ASPHALTENES WT% (max) | 0.06 | ||
| KIN. VIS@100 c(min) | 11 | ||
| WATER CONTENT vol % | 0.02 | ||
| COLOR (min) | 3 | ||
| POUR POINT c max | -3 | ||
| VISCOSITY INDEX ( min) | 88.9 |
| Property | Unit | Test | Value |
|---|---|---|---|
| SPECIFIC GRAVITY @ 15.56 /15.56 °C | ASTM D 4052 | 0.9798 | |
| API | ASTM D 1298 | 12.92 | |
| SULPHUR CONTENT (Total) | wt% | ASTM D 4294 | 2.85 |
| BASE SEDIMENT & WATER | vol% | ASTM D 1796 | 0.05 |
| WATER CONTENT | vol% | ASTM D 4006 | <0.05 |
| SALT CONTENT | P.T.B | ASTM D 3230 | 10 |
| FLASH POINT ° C | ° C | ASTM D 93 | 164 |
| " " @ 40 ° C | mm2/Sec | ASTM D 445 | 907 |
| " " @ 50 ° C | mm2/Sec | ASTM D 445 | 376 |
| POUR POINT | ° C | ASTM D 5853 | 3 |
| ASH CONTENT | Wt.% | ASTM D 482 | 0.03 |
| ASPHALTENES Wt.% | wt% | IP 143 | 5.4 |
| WAX CONTENT | wt% | BP 237 | 7.5 |
| DROP MELTING POINT OF WAX | ° C | IP 133 | 72 |
| CARBON RESIDUE CONRADSON | wt% | ASTM D 189 | 13.4 |
| ACIDITY , TOTAL | mgKOH/gr | UOP 565 | 0.08 |
| CALORIFIC VALUE | Kcal/Kg | CALCULATED | 10141 |
| NICKEL CONTENT | PPm | ASTM D 5863 | 39 |
| PPm | PPm | ASTM D 5863 | 137 |
| PPm | PPm | ASTM D 5863 | <1 |
| PPm | PPm | ASTM D 5863 | <1 |
| PPm | PPm | ASTM D 5863 | 13 |
| Property | Unit | Test | Value |
|---|---|---|---|
| Specific Gravity @25/25(°C) | ASTM D-70 | 1.01-1.05 | |
| Penetration @25(°C) | ASTM D-5 | 80-100 | |
| Softening point(°C) | ASTM D-36 | 43 min | |
| Ductility@@25(°C) | ASTM D-113 | 100 min | |
| Loss on Heating (%wt) | ASTM D-6 | 0.5 max | |
| Drop in Penetration After Heating% | ASTM D-6 & D-5 | 20 max | |
| Flash Point (°C) | ASTM D-92 | 225 min | |
| Solubility In CS2 (%wt) | ASTM D-4 | 99 min | |
| Penetration Index | -1.142857143 | ||
| Spot Test (°C) | * A.A.S.H.O.T.102 | negative |
| Property | Unit | Test | Value |
|---|---|---|---|
| Specific Gravity @25/25(°C) | ASTM D-70 | 1.01-1.04 | |
| Penetration @25(°C) | ASTM D-5 | 100/120 | |
| Softening point(°C) | ASTM D-36 | 42-49 | |
| Ductility@@25(°C) | ASTM D-113 | 100 min | |
| Loss on Heating (%wt) | ASTM D-6 | 0.2 max | |
| Drop in Penetration After Heating% | ASTM D-6 & D-5 | 20 max | |
| Flash Point (°C) | ASTM D-92 | 250 min | |
| Solubility In CS2 (%wt) | ASTM D-4 | 99.5 min | |
| Organic Matter Insoluble In CS2(%wt) | ASTM D-4 | 0.2 max | |
| Spot Test (°C) | * A.A.S.H.O.T.102 | negative |
| Property | Unit | Test | Value |
|---|---|---|---|
| Specific Gravity @25/25(°C) | ASTM D-70 | 1.01-1.05 | |
| Penetration @25(°C) | ASTM D-5 | 85/100 | |
| Softening point(°C) | ASTM D-36 | 45-52 | |
| Ductility@@25(°C) | ASTM D-113 | 100 min | |
| Loss on Heating (%wt) | ASTM D-6 | 0.5 max | |
| Drop in Penetration After Heating% | ASTM D-6 & D-5 | 20 max | |
| Flash Point (°C) | ASTM D-92 | 250 min | |
| Solubility In CS2 (%wt) | ASTM D-4 | 99.5 min | |
| Organic Matter Insoluble In CS2(%wt) | ASTM D-4 | 0.2 max | |
| Spot Test (°C) | * A.A.S.H.O.T.102 | negative |
| Property | Unit | Test | Value |
|---|---|---|---|
| Specific Gravity @25/25(°C) | ASTM D-70 | 1.01-1.06 | |
| Penetration @25(°C) | ASTM D-5 | 60/70 | |
| Softening point(°C) | ASTM D-36 | 49-56 | |
| Ductility@@25(°C) | ASTM D-113 | 100 min | |
| Loss on Heating (%wt) | ASTM D-6 | 0.2 max | |
| Drop in Penetration After Heating% | ASTM D-6 & D-5 | 20 max | |
| Flash Point (°C) | ASTM D-92 | 250 min | |
| Solubility In CS2 (%wt) | ASTM D-4 | 99.5 min | |
| Organic Matter Insoluble In CS2(%wt) | ASTM D-4 | ||
| Spot Test (°C) | * A.A.S.H.O.T.102 | negative |
| Property | Unit | Test | Value |
|---|---|---|---|
| specific Gravity @25/25(°C) | ASTM D-70 | 1.01-1.06 | |
| Penetration @25(°C) | ASTM D-5 | 40/50 | |
| Softening point(°C) | ASTM D-36 | 52-60 | |
| Ductility@@25(°C) | ASTM D-113 | 100 | |
| Loss on Heating (%wt) | ASTM D-6 | 0.2 max | |
| Drop in Penetration After Heating% | ASTM D-6 & D-5 | 20 max | |
| Flash Point (°C) | ASTM D-92 | 250 min | |
| Solubility In CS2 (%wt) | ASTM D-4 | 99.5 min | |
| Organic Matter Insoluble In CS2(%wt) | ASTM D-4 | ||
| Spot Test (°C) | * A.A.S.H.O.T.102 | negative |
| Property | Unit | Test | Value |
|---|---|---|---|
| specific Gravity @25/25(°C) | ASTM D-70 | 1.01-1.06 | |
| Penetration @25(°C) | ASTM D-5 | 30/40 | |
| Softening point(°C) | ASTM D-36 | 55-63 | |
| Ductility@@25(°C) | ASTM D-113 | 100 min | |
| Loss on Heating (%wt) | ASTM D-6 | 0.2 max | |
| Drop in Penetration After Heating% | ASTM D-6 & D-5 | 20 max | |
| Flash Point (°C) | ASTM D-92 | 250 min | |
| Solubility In CS2 (%wt) | ASTM D-4 | 99.5 min | |
| Organic Matter Insoluble In CS2(%wt) | ASTM D-4 | ||
| Spot Test (°C) | * A.A.S.H.O.T.102 | negative |
VOGAS is primarily a distributor and Physical trader of petrochemical products,oil and gas derivatives. The company owns and has under charter and operates its own fleet of oil, chemical and LPG tanker vessels, sources and manages land-based transport and storage facilities and provides consultancy services across these and other areas including engineering for refineries and manufacturing plants.
Our multi-sourcing trading division has extensive experience and knowledge in markets across the world, and in particular the Middle East, Far East, Asia and Africa. We offer a seamless combination of global reach, responsive communication, technical skills, local market knowledge and a total commitment to long-term mutually beneficial relationships with all our customers and suppliers.
At VOGAS, we are Long-term thinkers. Building relationships, while preserving the environment, is what drives our corporate culture. We are transparent, professional, experienced and we never over-promise. From sourcing products and logistics services to shipping, we always strive to do what's best for our clients and the world we live and operate in.
But most of all, in an industry filled with jargon and small-print, we are straight-talking. From sourcing products and logistics services to engineering manufacturing plants, we always strive to do what’s best for our clients and the world we live and operate in.
Our global distribution process is managed with tireless attention to detail, ensuring that the products you need arrive as ordered and on time. This is achieved through a combination of our own shipping fleet, chartered vessels and an extensive network of contracted land and ocean distribution specialists in markets around the world. The group currently owns and has under period charter fully refrigerated and pressurised LPG tankers as well as clean and dirty oil tankers.
Each order is tracked from the time the product leaves the plant until it is delivered to its final destination and is always followed up by a member of our client service team. We fully understand that your reputation depends on us and the fulfillment of our role in the supply chain. We never make a promise we cannot keep.
To us, storage is much more than storing products. We see it as a strategic tool to enhance our clients’ competitiveness. Through information such as where your manufacturing plant is and where you markets are, together with ongoing research efforts, we are able to formulate a storage plan that will maximize efficiencies and reduce transport costs and time.
This plan takes into account every facet of your business requirements and plugs into your world-wide network of specialist storage partners, giving you a tailor made “Plan, Facilitate, Manage” solution that will positively impact your bottom line significantly.
A relatively new addition to our service channels, our engineering team specializes in the conception and design of a number of different types of petrochemical manufacturing plants. Using proprietary advanced IP, our turn-key service offers a design, build and maintain solution certified by the Düsseldorf Chamber of Commerce. With all projects, we study our client’s needs and expectations, filtering them through our own detailed feasibility process, before commencing the design and budgeting stage. This ensures a clear roadmap and reduces the risk of delays or costly variations. Most importantly, it ensures that all milestones are met.
Dubai
E: info@vogas.com
Shanghai
T: +86 21 56043871
E: info@vogas.com
Singapore
T: +65 6339 2776
E: info@vogas.com
Shanghai
T: +86 21 56043871
E: info@vogas.com
DUBAI
E: info@vogas.com
singapore
T: +65 6339 2776
E: info@vogas.com
